Size and weight (30GB model)
Height: 4.1 inches
Width: 2.4 inches
Depth: 0.43 inch
Weight: 4.8 ounces
Size and weight (80GB model)
Height: 4.1 inches
Width: 2.4 inches
Depth: 0.55 inch
Weight: 5.5 ounces
In the box
iPod
Earphones
USB 2.0 cable
Dock adapter for use with Universal Dock
Case
Quick Start guide
Capacity
30GB or 80GB hard drive(1)
Holds up to 7,500 (30GB) or 20,000 songs (80GB) in 128-Kbps AAC format(2)
Holds up to 25,000 iPod-viewable photos(3)
Holds up to 40 hours (30GB) or up to 100 hours (80GB) of video(4)
Stores data via USB hard drive
Display
2.5-inch (diagonal) QVGA transflective, over 65,000-color liquid crystal display with white LED backlight
320 by 240 pixel resolution, .156-mm dot pitch
Support for display of multiple languages and characters simultaneously
Audio
Frequency response: 20Hz to 20,000Hz
Audio formats supported: AAC (16 to 320 Kbps), Protected AAC (from iTunes Store), MP3 (16 to 320 Kbps), MP3 VBR, Audible (formats 2, 3 and 4), Apple Lossless, AIFF and WAV
User-configurable maximum volume limit
Video
Video formats supported: H.264 video, up to 1.5 Mbps, 640 by 480 pixels, 30 frames per sec., Low-Complexity version of the H.264 Baseline Profile with AAC-LC audio up to 160 Kbps, 48 kHz, stereo audio in .m4v, .mp4, and .mov file formats; H.264 video, up to 768 Kbps, 320 by 240 pixels, 30 frames per sec., Baseline Profile up to Level 1.3 with AAC-LC audio up to 160 Kbps, 48 kHz, stereo audio in .m4v, .mp4, and .mov file formats; MPEG-4 video, up to 2.5 Mbps, 640 by 480 pixels, 30 frames per sec., Simple Profile with AAC-LC audio up to 160 Kbps, 48 kHz, stereo audio in .m4v, .mp4, and .mov file formats
Headphones
Earphones
Frequency response: 20Hz to 20,000Hz
Impedance: 32 ohms
Mac system requirements
Macintosh computer with USB 2.0 port
Mac OS X v10.3.9 or later
iTunes 7 or later(5)
Windows system requirements
PC with USB 2.0
Windows 2000 with Service Pack 4 or later, or Windows XP Home or Professional with Service Pack 2 or later
iTunes 7 or later(5)
Languages
Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish
Additional language support for display of song, album and artist information: Bulgarian, Croatian, Romanian, Serbian, Slovak, Slovenian, and Ukrainian
Environmental requirements
Operating temperature: 32 degrees to 95 degrees F (0 degrees to 35 degrees C)
Nonoperating temperature: -4 degrees to 113 degrees F (-20 degrees to 45 degrees C)
Relative humidity: 5% to 95% noncondensing
Maximum operating altitude: 10,000 feet (3000 m)
Input and output
iPod
-- Dock connector
-- 3.5-mm stereo headphone minijack
iPod Universal Dock
-- Dock connector
-- Audio and composite video output
-- S-video output
Power and battery(6)
Built-in rechargeable lithium ion battery
Playback time (30GB model)
-- Music playback time: Up to 14 hours when fully charged
-- Photo slideshow with music viewing time: Up to 4 hours when fully charged
-- Video playback time: Up to 3.5 hours when fully charged
Playback time (80GB model)
-- Music playback time: Up to 20 hours when fully charged
-- Photo slideshow with music viewing time: Up to 6 hours when fully charged
-- Video playback time: Up to 6.5 hours when fully charged
Charging via USB or FireWire to computer system or power adapter (sold separately)
-- Fast-charge time: about 2 hours (charges up to 80% of battery capacity)
-- Full-charge time: about 4 hours
Comparison
Storage/capacity: 30GB (7,500 songs) or 80GB (20,000 songs)
Color: black or white
Battery life:
-- 30GB: Up to 14 hours of music playback; up to 4 hours of slideshows with music; up to 3.5 hours of video playback
-- 80GB: Up to 20 hours of music playback; up to 6 hours of slideshows with music; up to 6.5 hours of video playback
Display: 2.5-inch (diagonal) color LCD with LED backlight
Ports: Dock connector, stereo minijack, composite video and audio through minijack
Connectivity: USB through dock connector; composite video (with AV cable, sold separately) and audio through headphone jack or line out on the iPod Universal Dock (sold separately)
Charge time: About 4 hours (2-hour fast charge to 80% capacity)
Audio support: AAC (16 to 320 Kbps), Protected AAC (from iTunes Store), MP3 (16 to 320 Kbps), MP3 VBR, Audible (formats 2, 3 and 4), Apple Lossless, WAV, AIFF
Photo support: Syncs iPod-viewable photos in JPEG, BMP, GIF, TIFF, PSD (Mac only), and PNG formats
Video support: H.264 video, up to 1.5 Mbps, 640 by 480 pixels, 30 frames per sec., Baseline Low-Complexity Profile with AAC-LC audio up to 160 Kbps, 48 kHz, stereo audio in .m4v, .mp4, and .mov file formats; H.264 video, up to 768 Kbps, 320 by 240 pixels, 30 frames per sec., Baseline Profile up to Level 1.3 with AAC-LC audio up to 160 Kbps, 48 kHz, stereo audio in .m4v, .mp4, and .mov file formats; MPEG-4 video, up to 2.5 Mbps, 640 by 480 pixels, 30 frames per sec., Simple Profile with AAC-LC audio up to 160 Kbps, 48 kHz, stereo audio in .m4v, .mp4, and .mov file formats
Size:
-- 30GB: 4.1 x 2.4 x 0.43 inches
-- 80GB: 4.1 x 2.4 x 0.55 inches
Weight:
-- 30GB: 4.8 ounces
-- 80GB: 5.5 ounces
Included accessories: Earphones, USB cable, dock adapter, case
Limited warranty and service
Your iPod comes with single-incident telephone support for the first 90 days and a one-year limited warranty. Purchase the AppleCare Protection Plan for iPod to extend your service and support to two full years. Only the AppleCare Protection Plan provides you with direct telephone support from Apple technical experts and the assurance that repairs will be handled by Apple-certified technicians using genuine Apple parts. For more information, visit the Apple support site or call 800-823-2775.
1. 1GB = 1 billion bytes; actual formatted capacity less.
2. Song capacity based on 4 minutes per song and 128-Kbps AAC encoding; actual capacity varies by content.
3. Photo capacity is based on iPod-viewable photos transferred from iTunes.
4. Video capacity based on H.264 1.5-Mbps video at 640 by 480 resolution combined with 128-Kbps audio; actual capacity varies by content.
5. iPod and iTunes are for legal or rightholder-authorized copying only. Don't steal music.
6. Rechargeable batteries have a limited number of charge cycles and may eventually need to be replaced. Battery life and number of charge cycles vary by use and settings. See Apple's site for more information.
