Stanton T.90 USB Direct Drive Turntable

The Stanton T.90 USB is a professional quality turntable with high-torque direct drive motor and a USB output, combining the latest digital technology with a unique style that can only be Stanton. With Key Lock built-in, DJs can adjust the tempo of a record without affecting pitch, while USB and S/PDIF digital outputs make the T.90USB great for archiving vinyl.

Features
Pro-quality turntable with high-torque direct drive motor and unique design

S-Shape tone arm for lower distortion and superior tracking

Unique digital features like Key Lock (master tempo) and S/PDIF output

2 Start/Stop switches for mix or battle setup

3 playback speeds (33, 45, 78 RPM), plus quartz lock and target light

Pitch control slider with selectable range (+ / - 8%, 12%)

Includes Stanton 500B cartridge, slip mat and cloth dust cover

Includes Cakewalk Pyro 5 music and sound editing software

Technical Info

Turntable Section
Frequency Response: 30 Hz to 20 kHz +1/- 2 dB/ RIAA filter

THD+N: < 0.03% at 1 kHz

S/N Ratio: Line <-65 dB

Digital Output (SPDIF): 0.5Vp-p (Load 75 ohms)

Type: 3-speed full manual

Motor: 8 pole, 3 phase, brushless DC motor

Speeds:33 1/3 and 45rpm and 78 rpm

Wow and Flutter: Less than 0.15% WRMS (JIS WTD) with 33 1/3 rpm

Pitch Controls: +/- 8%, +/-12%

Starting Torque: More than 1.6 kgf.cm

Starting Time: Less than 1 sec with 33 1/3 rpm

Braking Time: Less than 1 sec with 33 1/3 rpm

Braking System: Electronic Brake

Pitch Bend: +/- 6%

Time for Speed Change:
Less than 1 sec with 33 1/3 rpm
Less than 1 sec from 45 to 33 1/3 rpm
Less than 1 sec from 33 1/3 to 78 rpm

Audio Output: Phono/Line output

USB Function: A/D,D/A 16-bit 44.1KHz or 48KHz USB selectable

Computer interface: USB 1.1 compliant, Windows XP or Mac OSX

Tone Arm Section
Tone arm type: Static balanced S-Shape tonearm for lower distortion and reduced record-ware

Effective Arm Length: 230.5mm

Tracking Force Range: 0-3g

Applicable Cartridge Weight: 3-4g

Add turntable control to your computer DJ system! Direct-drive motor with USB output. Onboard key-lock adjusts tempo without changing pitch. Three playback speeds. Includes cartridge, slip mat, and dust cover, plus Cakewalk Pyro 5 software.
