The Stanton T.90 USB is a professional quality turntable with high-torque direct drive motor and a USB output, combining the latest digital technology with a unique style that can only be Stanton. With Key Lock built-in, DJs can adjust the tempo of a record without affecting pitch, while USB and S/PDIF digital outputs make the T.90USB great for archiving vinyl.
Features
Pro-quality turntable with high-torque direct drive motor and unique design
S-Shape tone arm for lower distortion and superior tracking
Unique digital features like Key Lock (master tempo) and S/PDIF output
2 Start/Stop switches for mix or battle setup
3 playback speeds (33, 45, 78 RPM), plus quartz lock and target light
Pitch control slider with selectable range (+ / - 8%, 12%)
Includes Stanton 500B cartridge, slip mat and cloth dust cover
Includes Cakewalk Pyro 5 music and sound editing software
Technical Info
Turntable Section
Frequency Response: 30 Hz to 20 kHz +1/- 2 dB/ RIAA filter
THD+N: < 0.03% at 1 kHz
S/N Ratio: Line <-65 dB
Digital Output (SPDIF): 0.5Vp-p (Load 75 ohms)
Type: 3-speed full manual
Motor: 8 pole, 3 phase, brushless DC motor
Speeds:33 1/3 and 45rpm and 78 rpm
Wow and Flutter: Less than 0.15% WRMS (JIS WTD) with 33 1/3 rpm
Pitch Controls: +/- 8%, +/-12%
Starting Torque: More than 1.6 kgf.cm
Starting Time: Less than 1 sec with 33 1/3 rpm
Braking Time: Less than 1 sec with 33 1/3 rpm
Braking System: Electronic Brake
Pitch Bend: +/- 6%
Time for Speed Change:
Less than 1 sec with 33 1/3 rpm
Less than 1 sec from 45 to 33 1/3 rpm
Less than 1 sec from 33 1/3 to 78 rpm
Audio Output: Phono/Line output
USB Function: A/D,D/A 16-bit 44.1KHz or 48KHz USB selectable
Computer interface: USB 1.1 compliant, Windows XP or Mac OSX
Tone Arm Section
Tone arm type: Static balanced S-Shape tonearm for lower distortion and reduced record-ware
Effective Arm Length: 230.5mm
Tracking Force Range: 0-3g
Applicable Cartridge Weight: 3-4g
