Unsurpassed UHF performance with 120dB dynamic range and operation up to 500 feet line-of-sight.
Features:
1000 user switchable UHF frequencies per band
Two complete front end True Diversity™ circuitry for eliminating dropouts and maximizing range
Sophisticated IF filtering for multiple UWS-1K system operation in the same location simultaneously
Tone Squelch circuitry for protection from RF interference
Front panel backlit LCD display indicates the selected channel/frequency, SQL level, receiver RF level, A/B diversity status, and Audio LED bar graph for AF level
Front panel touch control buttons and user friendly configuration menus
Download feature sends channel program to transmitter via IR sender
Back panel balanced XLR mic level and unbalanced 1/4" jack audio outputs, and TNC jacks for dual antennas (with 9VDC/100mA phantom power for powering optional remote powered antennas as needed for longer antenna cable runs)
Rack mountable with optional single or dual (side-by-side) rackmount kits
Externally powered with 16.5V/0.4A DC adapter included
UH-1K and UB-1K Transmitters:
Choice of transmitters: UH-1K handheld or UB-1K bodypack, both 1000-channels selectable
UH-1K handheld is a sleek, durable unit with an internal antenna system and the superior Nady DM-10D neodymium cartridge for clear, powerful audio, and the powerful audio section provides maximum feedback rejection, and minimal handling noise
UB-1K bodypack is a versatile unit with a unique 3-pin Mini XLR input connector for instrument, lavalier mic, or headworn mic (with convenient DC phantom powering)
An input level control allows optimal audio gain adjustment
UH-1K and UB-1K IR link features Infrared downloading of selected group/channel information from receiver for easy channel programming
UH-1K and UB-1K transmitters feature touch power ON/OFF and Mute control button, Low battery status and Mute LED indicator
UH-1K and UB-1K both operate on 2 AA batteries for the longest reliable and economical battery life
