FireWire Audiophile is a compact, FireWire-compatible audio/MIDI interface that takes the legacy of M-Audio's award-winning Audiophile line to the next level. 4 x 6 audio I/O combines with powerful on-board mixing in a mobile package that's perfect for live performance, home recording, and digital DJ work.
Stereo headphone output with A/B switching between assignable sources allows precuing for DJs and mobile musicians?and the assignable aux bus is perfect for creating dedicated headphone mixes and effect sends. You also get zero-latency hardware direct monitoring, ultra-low latency ASIO software direct monitoring, and 1 x 1 MIDI I/O. FireWire Audiophile even has AC-3 and DTS passthrough for surround sound playback.
Features
4 x 6 24-bit/96kHz I/O
2 x 4 analog operation (RCA)
Digital S/PDIF (coaxial) I/O w/ 2-channel PCM
Digital out also supports AC-3/DTS surround sound
Headphone output with dedicated level control
Flexible software-controlled mixing of hardware and software I/O
Aux sends on all channels and aux output assign allows for dedicated headphone mixes and sends to external effects
User-assignable front-panel level control (output, input, software return, aux send)
Zero-latency hardware direct monitoring
Low-latency ASIO software direct monitoring
Momentary switch for A/Bing two software-assignable headphone sources or switching ASIO monitoring on/off
1 x 1 16-channel MIDI I/O
Power on/off switch with indicator LED
Powered via FireWire bus* or included DC power supply
Two convenient high-bandwidth FireWire ports
Rugged steel construction
Technical Info
Specifications
Frequency Response: 20Hz-40kHz +/-0.40dB, 96kHz sample rate
Dynamic Range: 108dB A-weighted
Signal-to-Noise: 106dB A-weighted
Compatibility
ASIO 2
MME
Sound Manager
DirectX
Mac OS X Core Audio / Core MIDI
Minimum System Requirements - PC
Pentium III 500 MHz or higher
128 MB RAM
Windows 2000 (SP3)/Windows XP (SP1)
DirectX 8.1 or higher
6-pin FireWire port or adapter
Minimum System Requiremennt - Mac
Macintosh G3* 500 MHz or higher w/OS 9.2.2, 128 MB RAM;
G4* 500MHz w/OS 10.1.5 or OS 10.2.6 or greater, 256 MB RAM (OSX)
* G3/G4 accelerator cards not supported; native FireWire ports required
