Lexicon Ionix U82S USB 2.0 Recording Audio Interface

Lexicon IONIX U82S USB Audio Interface; When recording more than just a pastime. Lexicon understands your passion and in return inspires us to innovate. The IONIX series of Lexicon interfaces are Brilliantly designed to place the interface between your keyboard and monitor where you can reach all of your controls without having to move your attention to out-of-the-way racks putting your attention where it needs to be, right in front of you.

Features
USB 2.0 connection to DAW (up to 480 Mbps)

44.1 to 96 kHz sample rates (24 bit)

Analog XLR-1/4 inch combi-jack inputs

Analog 1/4 TRS (Stereo Main) outputs

DBX high voltage, ultra-low noise mic preamps on all analog mic/line inputs

48V Phantom power for each input pair

Input signal metering via 8 LED's per channel

Signal mixing and stereo bus signal metering

1/4 inch high output headphone connections

MIDI in/out

Zero latency monitoring

Low latency ASIO drivers

Lexicon Pantheon II VST/AU reverb plug-in

Supports Windows and Mac platforms

Software suite includes Steinberg's Cubase LE4 and Toontrack EZdrummer lite

All channels on the IONIX USB interfaces feature microphone preamps designed by dbx making them more than equipped for professional recordings for the best possible sound. The preamps run on high-voltage providing both stability and superior recording across a wide dynamic range. High performance A/D-D/A converters deliver the most accurate 24bit/96kHz audio you can find in this price range. Capture every subtle detail of your performance with IONIX interfaces.

Lexicon = World's Best Reverb
The included Pantheon II VST/AU reverb plug-in features 6 reverb types with 16 adjustable parameters, and 35 factory presets that range from Vocal to Live Sound and Special Effects. It's easy to complete your mix and make your music sound its best with the exquisitely rich, full reverbs that made Lexicon famous. No compromise performance - ergonomic brilliance.

Technical Info

General
Combi-jack Analog Inputs: 8

Simultaneous Recording Sources: 10

Microphone Preamps: 8

Hi-Z Instrument Inputs: 2

S/PDIF: Yes

MIDI: Yes

Headphone Connections: 2

1/4 inch Outputs: 2 (TRS Analog)

Microphone Inputs: Female XLR (Pin 2 Hot)
Input Impedance: 3k ohm (balanced)

Phantom Power: +48 Volts

Maximum gain: +55 dB

E.I.N. (at max gain):
- -127 dB @ 55dB gain typical (150O source)
- -130 dB @ 55dB gain typical A-weighted (150O source)

Maximum Input Level: +8 dBu

Frequency Response: +/-1.5 dB, 20Hz - 20kHz

THD+N: <0.02%, 20Hz - 20kHz, <0.002%, 1kHz, -6 dBu

Line Inputs: 1/4 inch TRS (balanced or unbalanced)
Input Impedance: 20k ohm balanced (13k O unbalanced)

Maximum Input Level: +18 dBu

Frequency Response: +/-1.5 dB, 20Hz - 20kHz

THD+N: <0.02%, 20Hz - 20kHz, <0.002%, 1kHz, +18 dBu

Instrument Input: 1/4 inch (TS unbalanced)
Input Impedance: 1M ohm

Maximum Input Level: +10 dBu

Frequency Response: +/-2.5 dB, 20Hz - 20kHz

THD+N: <0.08%, 1kHz, +4 dBu

Line Outputs: 1/4 inch TRS (balanced or unbalanced)
Level: +18 dBu maximum

Impedance: 32 ohm Balanced (16 ohm unbalanced)

Headphone Output: 1/4 inch stereo jack 250mW per channel at 50O

Other
MIDI Interface: 5 pin DIN connectors (MIDI in and MIDI out)

Sample Rate: 44.1, 48, 88.2 or 96 kHz (determined by computer application)

Dynamic Range:
- A/D (24 Bit): 108 dB typical, A-weighted, 20Hz - 20kHz
- D/A (24 Bit): 110 dB typical, A-weighted, 20Hz - 20kHz
- A/D/A (24 Bit): 106 dB typical, A-weighted, 20Hz - 20kHz

Power Requirements: 100/240 VAC, 50/60 Hz, 15 Watts

Rebates

Record 8 tracks at once with 8 XLR/TRS combo jacks.
