Manufacturer's Description for Korg EMX1 Electribe MX Production Station
Serious Genre-Warping Production Tools for Your Dance Creations
The Electribe series of Dance Tools defined a new standard, combining unique sound generation, pattern based programming, and intuitive knob-based interfaces. Thousands of forward-thinking musicians, DJs and producers continue to use them to create exciting and groundbreaking music.
The ELECTRIBEMX represents a new generation of Electribes - powerful dance music products that cover everything from laying down stunning tracks to creating exhilarating live performances. The EMX-1 comes housed in a sleek, rugged metal chassis. The new backlit LCD provides a wealth of information during programming or performance.
The intuitive step-time/realtime interface has been enhanced with a new Ribbon and Slider control. Effects, Motion Sequencing, and Pattern length have all been expanded. A brand-new filter lets you chose Low Pass, High Pass, Band Pass or Band Pass Plus.
Up to 256 patterns can be created and stored to the internal memory. You can combine patterns, add mute data and knob movements to create up to 64 songs. To get you started, a wide assortment of patterns covering house, hip-hop, R&B, electronica, drum'n'bass, techno, trance and more come preloaded - 196 in the ELECTRIBEMX. Using the last step function, you can easily adjust to any odd meter. Favorite patterns can be assigned to Pattern Sets for instant access. Data can be quickly saved and loaded via SmartMediaTM.
Audio inputs allow you to process external signals through the on-board filter and effects, and an extra pair of assignable outputs has been added as well. The front panel knobs and switches control all the most important sound parameters, allowing you to modify the sound in realtime as you perform, and giving you a hands-on feel like that of an analog synthesizer.
ELECTRIBEMX: Cutting-Edge MMT Synthesis Engine
Powered by one of the most advanced synthesizer engines in the world, the ELECTRIBEMX provides everything needed to create sophisticated dance music - nine drum parts, five synth parts, plus accent parts that let you add dynamic accents to the drum and synth parts (for a total of 16 parts).
The all-new MMT (Multi Modeling Technology) offers sixteen different oscillator algorithms, providing powerful analog synthesis models as well as sophisticated additive, PCM, chord, unison, combination, wave shaping, formant models and more. The built-in PCM library includes 207 drum PCM sounds and 76 synth PCM sounds ready for immediate use, ranging from powerful kicks and snares through amazingly unique organic sounds. External audio signals can be manipulated using the Comb Filter oscillator algorithm, and then further processed by the internal filter and effects.
A new 'Drive' parameter added to the filter produces the distinctive overdrive of analog circuitry, creating powerful and biting analog synth sounds. Each part features extensive LFO and EG modulation, allowing you to create wonderfully bizarre sounds.
The ELECTRIBEMX is Packed with Cutting-Edge Features
Twin Vacuum Tubes for Analog Warmth
Valve Force circuitry contains two vacuum tubes that add new power to your sound. The analog tube circuit adds a warmth and presence to your sound that cannot be duplicated digitally. The tube gain knob adjusts the level of the output signal passing through the vacuum tubes, creating dynamic sounds with the distinctive tonal quality that only tubes deliver.
3 Stereo Effect Processors to Radically Change Your Sound
The highly acclaimed Electribe effects have been enhanced to provide three multi-effect units available for simultaneous use. Each part can be independently routed to any of the three effects processors, and you can even use the Chain function to link multiple effects in series, opening up further sonic possibilities. Each processor offers 16 effect types ranging from traditional reverb, delay, flanger and chorus, as well as more modern offerings including tempo-based delay, talking modulator, grain shifter, decimator and more. The edits you make to each of the effects processors are saved with each pattern.
Powerful Arpeggiator with Ribbon Controller and Slider
A new ribbon controller and slider have been added, providing a remarkable realtime interface for accessing the powerful arpeggiator. Together, they allow you to enter pattern data or perform over a pattern quickly and with amazingly musical results. When playing a synth part, select a scale type or hold down a few notes - the ribbon controller will affect note duration, and the slider can be played in realtime to generate new phrases. For a drum part, touching the ribbon will trigger notes, and sliding your finger up and down will change the note resolution.
Motion Sequencing Brings Your Songs to Life
Motion Sequencing records your realtime knob tweaks and plays them back as part of the pattern. Two types of motion sequence are provided; one for effects and one for parts, and you can also edit the value of individual steps. Up to 24 motion sequences can be used in a single pattern, allowing you to control virtually every sound parameter. The Step Edit function allows you to adjust the value of individual steps.
Easy to Use Realtime and Step Style Sequencing
The 14 part keys and 16 step keys on the front panel of the ELECTRIBEMX allow for easy, intuitive song production. Realtime recording lets you record phrases as you perform, and step recording allows you to input the timing, pitch and duration one note at a time.
Variety of Tempo Sources
Using Auto BPM detection, the ELECTRIBEMX can follow the tempo of an external audio source. You can also use Tap Tempo to input the beat, set the tempo internally, or sync up to an external MIDI clock.
zZounds is an authorized dealer of
Korg products.
Sound Generation Method: Analog Modeling + PCM
Oscillator type: 16 (Synth Part)
Filter type: 4 (Synth Part)
Drive Circulation: Synth Part
Modulation Function: Assignable, Tempo Synchronization
Number of Waveforms: 207 drum PCM waveforms, 76 Synth PCM waveforms (16-bit, 44.1kHz)
Number of Parts: 16 total; 5 synth parts, 9 drum parts, 1 synthesizer accent part, 1 drum accent part
Memory: 256 patterns (192 preload), 64 songs (3 preload)
Effects: 16 types x 3 (Chain)
Sequencer: Pattern: Maximum 128 steps by part, Maximum 24 motion sequence by pattern
Song: Maximum 256 patterns
Arpeggiator: Ribbon + Slider, Scale
Output: L/Mono, R (phone jack: mono x 2), Individual 3, 4 (phone jack: mono x 2), Headphone (phone jack: stereo)
Input: Audio In (phone jack: mono)
MIDI: n, Out, Thru
External Memory: SmartMedia (4-128 MB, 3V)
Vacuum tube: 12AX x 2
Power Consumption: 24W
Power Supply: AC IN (AC9V)
Dimensions: 14.09 in.(W) x 10.08 in.(D) x 2.44 in.(H) 358(W) x 256(D) x 62(H) mm (including protrusions)
Weight: 3.1 kg / 6.83 lbs.
Accessories: AC adapter
*SmartMediaTM is a trademark of Toshiba Corporation.
Specifications subject to change without notice
