Model Name: Highway One Stratocaster (Upgrade)

Model Number: 011-1160-(Color#) and 011-1162-(Color#)

Series: Highway One Series

Colors:
(300) 3-Color Sunburst
(304) Daphne Blue
(306) Flat Black
(367) Honey Blonde
(375) Wine Transparent
(Satin Nitrocellulose Lacquer Finish)

Body: Alder

Neck: Maple, Modern 'C' Shape, (Satin Polyurethane Finish)

Fingerboard: Rosewood (p/n 011-1160) or Maple (p/n 011-1162), 9.5" Radius (241mm)

No. of Frets: 22 Jumbo Frets

Pickups: 3 Hot Single-Coil Strat(R) Pickups with Staggered Pole Pieces, Alnico 3 Magnets and Reverse Wound/Reverse Polarity Middle Pickup

Controls:
Master Volume
Tone 1. (Neck Pickup), Greasebucket Tone Circuit, (Rolls Off Highs without Adding Bass)
Tone 2. (Bridge Pickup), Greasebucket Tone Circuit, (Rolls Off Highs without Adding Bass)

Pickup Switching:
5-Position Blade:
Position 1. Bridge Pickup
Position 2. Bridge and Middle Pickup
Position 3. Middle Pickup
Position 4. Middle and Neck Pickup
Position 5. Neck Pickup

Bridge: Vintage Style Synchronized Tremolo

Machine Heads: Fender/Ping Standard Cast/Sealed Tuning Machines

Hardware: Chrome

Pickguard: 3-Ply Parchment

Scale Length: 25.5 in. (648 mm)

Width at Nut: 1.6875 in. (43 mm)

Unique Features:
Satin Nitrocellulose Lacquer Body Finish
Parchment Plastic Parts
Large '70s Style Headstock Shape
Large '70s Style Headstock Logo
Original Body Shape
Original Contour Body Decal on Headstock
H/S/S Pickup Routing
Reverse Wound/Reverse Polarity Middle Pickup

Strings: Fender Super Bullets 3250L, Nickel Plated Steel, (.009 to .042), p/n 073-3250-003

Accessories: Deluxe Gig Bag

Case: Deluxe Gig Bag

Introduced: 7/2006

Notice: Product Prices, Features And Specifications Are Subject To Change Without Notice
