Casio's newest portables utilize the high performance Zpi sound source to deliver the most realistic piano, organ, and synth sounds, plus a huge library of built-in tones, rhythms, and DSP settings. These powerful instruments feature an on-board sequencer and a mixer, for unmatched creative possibilities, plus powerful built-in speakers to take your performance to the next level. These keyboards are ideal for home/project studio use, open-mic performance, education/classroom applications, or simply for pure musical enjoyment.
For unlimited possiblities Casio has created a brand new keyboard program where wave files can be downloaded directly onto a keyboard via a PC. The full program is available at music.casio.com as a free download. Using this software, new tones, tones with wave data, drum sets with wave data, rhythms, standard MIDI files, songs registrations and DSP settings can be loaded onto a PC, edited and eventually loaded directly into the keyboard. All you need to get started is to visit music.casio.com, download the Data Management Software and you can begin transferring to the keyboard, onto a SmartMedia Card or Floppy Disk via a PC.
Features
Sustain Assignable
MIDI I/O
Memory Floppy Drive/SmartMedia
Polyphony (max) 32-Note
Auto Rhythms 140 Preset
Tones 790
Keys 76 Full Size
Demo Songs None
Technical Info
Keyboard
76 full-size keys
Touch sensitive (with On/Off)
32-note polyphonic
Sounds/Effects
790 Tones: 566 preset tones (300 Advanced tones, 128 General MIDI, 72 Various, 16 Drum sets, 50 Drawbar Organs)
plus 224 User programmable tones (100 User tone, 20 User tone +wave, 4 Drum set + wave, 100User Drawbar)
Piano Setting Switch to get instant access of Stereo Piano Sound
Drawbar Organ lets you control simulated organ sounds easily.
Synthesizer function lets you create and store your own sounds.
232 Digital Effects: 100DSP, 100 User effects, 16 Reverb, 16 Chorus
Digital Equalizer
Spilt & Layer function
Advanced Tone: the panel sounds with more playability featuring bigger wave memory, velocity split and strong DSP units.
Rhythms
140 Preset Rhythm including 20 piano patterns and 16 User Rhythms
156 One-Touch Presets
CASIO CHORD/Fingered Chord/Full-Range Chord auto-accompaniment systems
Auto-Harmonize
Other Features
Built-in Floppy Disk Drive/SmartMedia to save/load various internal data such as song memory
Internet Data Expansion System lets you download new sounds (including sound wave), patterns, songs, and keyboard
settings over MIDI from CASIO MUSIC SITE
Flash ROM to expand sounds, rhythms, and to download songs from the internet.
SMF Player to play the songs downloaded through the Internet.
Musical Information System (Backlit LCD) displays selections and status of Tone, Rhythm, Mixer and keyboard functions,
and Tempo
On-screen keyboard and music staff icons display notes and chords played, and metronome icon indicates the beat
Mixer function allows control over each MIDI channel and accompaniment part
6 tracks/5 songs Song Memory
Pitch Bend wheel and Modulation switch
MIDI IN/OUT jacks; 16 CHANNEL Multi-Timbral
Transpose and Tuning Control
Registration Memory (4 sets x 8 banks)
Assignable Pedal Jack (Sustain, Soft, Sostenuto, Rhythm Start/Stop)
Bass Reflex Speaker system with 4 speakers plus 2 ports for added bass response
Individual lineout L/R for external amplification system
1/4 in. stereo lineout/headphone jack; 6W+6W output
Operates on D batteries or optional AD-12 AC Adaptor
Dimensions (W x D x H) 43 3/16 x 16 11/16 x 6 5/16 in.
Weight: 22 lbs.
