Radial PZ-Pro Dual Channel Acoustic Preamp
zZounds Gear Experts Say...
Use this dual-channel acoustic preamp to toggle or blend two different sound sources with full control over their individual EQ and effects!
Overview
The Radial PZ-Pro is designed for instrumentalists and performers who take a no-compromise approach when it comes to tone, both on stage and in the recording studio. Dual input channels allow you to switch between or blend together two sources, with full control over the sound of each input.
Each channel has its own semi-parametric equalizer section and input level, along with individual filter controls to reduce feedback on stage. The second channel of the PZ-Pro also features a microphone input to allow any dynamic or condenser microphone to be used, including clip-on instrument mics or even vocal microphones.
An FX Loop with a wet/dry knob provides the ability to blend in as much or as little pedal effects as desired, with a footswitch to bring them in and out of the signal chain at a moment's notice. Finally, once your tone is completely dialed-in, balanced XLR direct outs feed the PA system or a recording interface, with both Pre-EQ and Post-EQ outputs available.
Each channel has its own semi-parametric equalizer section and input level, along with individual filter controls to reduce feedback on stage. The second channel of the PZ-Pro also features a microphone input to allow any dynamic or condenser microphone to be used, including clip-on instrument mics or even vocal microphones.
An FX Loop with a wet/dry knob provides the ability to blend in as much or as little pedal effects as desired, with a footswitch to bring them in and out of the signal chain at a moment's notice. Finally, once your tone is completely dialed-in, balanced XLR direct outs feed the PA system or a recording interface, with both Pre-EQ and Post-EQ outputs available.
Specs
- Input Impedance: 220k Ohm at input jack (10Meg Ohm when PZ Boost active)
- Output Impedance: XLR: 150 Ohm, 1/4" Amp Out: 1k Ohm, Tuner Out: 2.6k Ohm
- Frequency Response: 20Hz-20kHz (+/-0.5dB)
- Gain Range: +20dB (Instrument Input), +55dB (Mic Input), +10dB (PZ Boost), +15dB (Variable Boost)
- EQ Controls: 3-band EQ with semi-parametric mids, Variable notch filter and high-pass filter per channel
- Phantom Power: 48V phantom power on XLR mic input (channel B)
- Power Requirements: 15VDC 400mA, center-pin positive
- Signal-to-Noise Ratio: -91dB
- Total Harmonic Distortion: <0.005% @ 1kHz
- Maximum Input Level: Instrument: +20dBu, Microphone: 0dBu
- Maximum Output Level: +10dBu @ XLR output
- Output Impedance: XLR: 150 Ohm, 1/4" Amp Out: 1k Ohm, Tuner Out: 2.6k Ohm
- Frequency Response: 20Hz-20kHz (+/-0.5dB)
- Gain Range: +20dB (Instrument Input), +55dB (Mic Input), +10dB (PZ Boost), +15dB (Variable Boost)
- EQ Controls: 3-band EQ with semi-parametric mids, Variable notch filter and high-pass filter per channel
- Phantom Power: 48V phantom power on XLR mic input (channel B)
- Power Requirements: 15VDC 400mA, center-pin positive
- Signal-to-Noise Ratio: -91dB
- Total Harmonic Distortion: <0.005% @ 1kHz
- Maximum Input Level: Instrument: +20dBu, Microphone: 0dBu
- Maximum Output Level: +10dBu @ XLR output
Dimensions and Weight in Packaging
Base Item
- Shipping Weight: 5 lbs
- Shipping Dimensions: 14 x 6 x 3 in
- Manufacturer Part Number (MPN): R800 7089
