All in all more than 800 instrument voices are built in Yamaha PSR-S700. Many of these voices are coming from high end models – for example, the 14 Live! Voices, 18 Cool! Voices and 11 Sweet! Voices as well as 10 Mega! Voices. Mega! Voices feature various playing and performance sounds, for example finger slides and fret noises on guitar voices. These Mega! Voices are used in the programming of the 205 internal accompaniment styles, giving your performances a new level of realism.
For each Style there are four One Touch Settings so that you get the perfect instrumental setting by pressing just one button. The OTS-Link-Function allows you to change automatically through the One Touch Setting just by changing the Style-variation.
If you want to play a certain song and don’t know which style to choose, the powerful Music Finder feature can help. Simply select a song title or a keyword, all appropriate panel settings are reconfigured to match the genre, including the appropriate voices, style and effects. Music Finder+ also works with the Internet Direct Connection (IDC) feature, allowing you to download additional free Music Finder records and collections in addition to the wide selection built in to the instrument.
The large LCD display shows the song notation of a MIDI file (score) as well as lyrics (for MIDI songs that have score and lyric data).
In addition, PSR-S700 features both Pitch Bend and Modulation Wheels, allowing the player to have more control over instrumental and synth voices. A powerful Bass-Reflex-speaker system and 2 x 12 watts amplification make the PSR-S700 outstanding in sound quality, whilst the integrated Network-connector (LAN-Port) ensures ease of use with Yamaha’s unique Internet Direct Connection (IDC) feature. The USB-to-device connection opens the possibility to connect USB storage devices such as thumb drives to the instrument, giving you virtually unlimited memory capacity for user registrations, styles and songs.
In addition, the PSR-S700 also features a huge range of onboard recording and creativity unmatched by any other keyboard at the price.
Technical Info
Sound Source: AWM Stereo Sampling
Keyboard: 61 keys (C1–C6 with Initial Touch)
Display: 320 X 240 dots QVGA Color LCD
Polyphony (max): 96
Voice Selection: 317 voices + 480 XG voices 16 Drum/SFX Kits + GM2 + GS voices for GS Song playback
MegaVoice: 10
Live! Voice: 14
Cool! Voice: 18
Sweet! Voice: 11
Organ Flutes: 10
Regular Voice: 254
Voice Editing (Voice Set): Yes
Effect Blocks: Reverb/Chorus/DSP 6
Effect Types:
(Reverb/Chorus/DSP)
Reverb: 34 Preset + 3 User
Chorus: 29 Preset + 3 User
DSP 1: 191 Preset + 3 User
DSP 2-4: 106 Preset + 10 User
Effect Types: Master EQ 5 Preset + 2 User
Effect Types: Part EQ 28 Parts
Accompaniment Style
Pro Styles: 193
Session Styles: 12
Mega Voice/Style: Yes
Fingering: Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard
Style Creator: Yes
OTS (One Touch Setting): 4 for each Style
OTS Link: Yes
Music Finder: Preset Yes
Music Finder: Edit Yes
RAM Capacity: 120 KB
Preset Songs: 5 samples
Guide: Follow Lights, Any Key, Karao-Key, Vocal CueTIME Follow Lights, Any Key, Karao-Key
Performance assistant technology: YES
Recording: Quick Recording, Multi Recording, Step Recording, Song Editing
Record Channels: 16
Preset: 4 Pads x 80 Banks
Internet Direct Connection: LAN Port, Wireless Game Adaptor (via LAN Port), External Adaptor (via USB to DEVICE)
USB Flash Memory: YES
Floppy Disk (2HD, 2DD): External Adaptor (via USB TO DEVICE)
Hard Disk: External Adaptor (via USB TO DEVICE)
Flash Memory (Internal): 560 KB
Memory Card (SmartMedia, etc.): External Adaptor (via USB TO DEVICE)
Tempo Range: 5 - 500, Tap Tempo
Metronome: YES
Sound: Bell on/off
Registration Memory Buttons: 8
Registration Sequence / Freeze: Yes
Demo: Yes
Language for Display: 6 Languages (English, Japanese, German, French, Spanish, Italian)
Direct Access: Yes
Transpose: Keyboard/Song/Master
Scale Type: 9
USB to HOST: Yes
USB to DEVICE: Yes
Other Connectors: PHONES, MIDI (IN, OUT), FOOT PEDAL (1, 2), AUX IN (R, L/L+R), OUTPUT (R, L/L+R), LAN
Pedal Functions: Volume, Sustain, Sostenuto, Soft, Glide, Portamento, Pitchbend, Modulation, DSP Variation, Song PLAY/PAUSE, Style START/STOP, etc.
Amplifiers: 2 W x 2
Speakers: (12 cm + 5 cm) x 2
Power Consumption: 35 W
Dimensions [W x D x H] 1003 x 148 x 433 mm (39 5/8 x 5 7/8 x 17 1/8 in.)
Weight: 11.5 kg (25 lbs., 5 5/8 oz)
Optional accessories
Footswitch: FC4/FC5
Foot Controller: FC7
Floppy Disk Drive: UD-FD01
AC Power Adaptor: PA-300B/PA-300
Keyboard stand: L-6/L-7 (The exterior size of the PSR-900/700 is beyond the limits as described in the L-6 Assembly Instructions. However, Yamaha has determined through tests that the stand can be safely used for the instrument.)
