For the aspiring musician, songwriter, or music educator looking for the best value in an entry-level multi-track recording system, the Porta 02 can't be beat. With great sound quality, easy operation, and full compatibility with consumer stereo cassette decks, this economical 4-track recorder lets you record, overdub, and mixdown to standard cassette.
Features
4-track integrated mixer/cassette multi-track recorder
2 mic/line input channels
4-channel mixer - level and pan controls on each
Standard 1-7/8 ips tape speed
Headphone monitor output with level control
2-track simultaneous record capability
Technical Info
Simultaneous Record/Play Tracks: 2 Record/4 Play
Mixer Channels: 4 Tape Returns
Overall Frequency Response: 50Hz-12.5kHz ?3dB
Overall Signal to Noise Ratio: >43dB
Wow/Flutter (WRMS): <0.18%
Tape Speed(s): 4.76cm/sec (1-7/8 ips)
Inputs
(2) 1/4 in. Mic/Line
Outputs
Line Output: RCA unbalanced
Headphone Output: 1/4 in. TRS
Power Consumption: 7W
Dimensions: 300 x 80 x 205 mm
Weight: 1.5 kg
Fast Winding Time: 120 seconds for C-60
ABC done. Just insert a cassette, plug in your mic or guitar, record 4 tracks (2 tracks at once), then play back and mix through the built-in mixer.
