The DM-2100 2.1-ch Speaker System is an affordable way to add accurate reference monitoring with a subwoofer for enhanced bass response. The left and right speakers each offer 15 watts of power, while the 50-watt subwoofer provides a powerful low-end boost. And with 24-bit/96kHz digital inputs, the DM-2100 is perfect for use with Roland/BOSS digital studios and instruments, or with computer systems and more.
Features
Affordable 2.1-channel monitoring system with 24-bit/96kHz digital inputs
Powered bass reflex speakers with 15 watts per side and flat frequency response
Active subwoofer with 50-watt ampli fier for increased low end
Front-mounted controls convenient located on right speaker
Coaxial and optical digital inputs, plus analog inputs (RCA and 1/4-in. type)
Sleek black wooden cabinets with magnetic shielding
It is way cool to stay digital throughout your signal path! 2 separate line inputs for mixing, 2 sources with separate volume controls, coaxial and optical digital inputs, plus analog inputs (RCA and 1/4 in. type). The cabinets offer magnetic shielding. Hooking up the DM-2100 is a snap. All inputs go directly into the right speaker, which serves as the preamp. The subwoofer then supplies power for the entire system via dedicated left and right speaker outputs. All controls - including power, input levels, Tone and Low Boost - can be easily adjusted from the right speaker's front panel. Hearing your music with heart-pumping bass was never so easy, clean and affordable.
Technical Info
Specifications
Rated Output Power: 50W + 15W + 15W
Speaker:
- Subwoofer: 16cm
- Satellite Units: 9.2cm
Nominal Input Level:
- Line 1: -10dBu
- Line 2: -10dBu
Input Impedance: 18kOhms
Controls:
- R Channel: Bass Control Knob, Treble Control Knob, Volume 1 (Digital In/ RCA pin), Volume 2 (1/4 in. phone), Power Switch, Digital Input Select Switch, Phase Switch
Connectors:
- R Channel: Line 1 Jack (L, R; RCA pin), Line 2 Jack (L (MONO), R; 1/4 in. phone), Optical Input Connector, Coaxial Input Connector, Dedicated connector for power control and audio signal, Channel Input Jack (R; RCA pin)
- L Channel: Channel Input Jack (L; RCA pin)
- Sub Woofer: Dedicated connector for power control and audio signal, Channel Output Jacks (L, R; RCA pin), AC In Jack
Digital Input:
- Sampling Rate: 32/44.1/48/96 kHz
- D/A: Convertor 24 bits
Power Supply: AC117, 230 or 240V
Dimensions (W x D x H):
- Satellite Units: 130 x 160 x 200 mm
- SubWoofer: 240 x 300 x 330 mm
Accessories: Speaker Cables (RCA pin type), Dedicated Cable for power control and audio signal, Power Cable
