The Classic Player Jaguar Special guitar updates Fender's iconic Jaguar model with some thoroughly modern improvements. These include hotter pickups, a redesigned Adjusto-Matic bridge with floating tremolo tailpiece, a 9.5 fingerboard radius and an improved neck pocket with increased back-angle for improved stability and sustain.
The tremolo plate has been moved closer to the bridge to increase break angle and sustain. A screw in tremolo arm increases stability and control when executing divebombs.
Technical Info
Model Name: Classic Player Jaguar Special
Model Number: 014-1700-(Color#)
Series: Classic Player Series
Colors: (300) 3-Color Sunburst, (309) Candy Apple Red, (Polyester Finish)
Body: Alder
Neck: Maple, “C” Shape, (Nitrocellulose Lacquer Finish)
Fingerboard: Rosewood, 9.5 in. Radius (241mm)
No. of Frets: 22 Medium Jumbo Frets
Pickups: 2 Special Design Hot Jaguar Single-Coil Pickups (Neck & Bridge)
Controls:
- “Lead” Circuit:
2-Position Tone Switch, Volume, Tone,
- “Rhythm” Circuit:
Volume, Tone, Circuit Selector Switch
Pickup Switching: 2-On/Off Slide Switches, One for Each Pickup
Bridge: Fender Adjusto-Matic Bridge with Vintage Style “Floating” Tremolo Tailpiece and Tremolo Lock Button
Machine Heads: Fender/Ping Vintage Style Tuning Machines
Hardware: Chrome
Pickguard:
- 4-Ply Brown Shell on:
(800) 3-Color Sunburst
- 3-Ply Mint Green on:
(809) Candy Apple Red
Scale Length: 24 in. (610 mm)
Width at Nut: 1.650 in. (41 mm)
Unique Features:
- New Pickups with Fatter Tone and More Output,
- Adjusto-Matic Bridge,
- Medium Jumbo Frets,
- New Neck Pocket Cut Provides Better Pitch,
- 9.5 in. Radius,
- Trem Plate Moved Closer to Bridge to Increase Break Angle and Sustain,
- Screw-In Tremolo Arm,
- Black Plastic Knobs and Switches
Strings: Fender Super 250R, Nickel Plated Steel
Gauges: (.010, .013, .017, .026, .036, .046), p/n 073-0250-006
Accessories Included: Deluxe Gig Bag
Case: Deluxe Gig Bag
Introduced: 6/2008
Notice: Product Prices, Features, Specifications and Availability Are Subject To Change Without Notice
