The new V50-112 two-channel combo loudly announces the new generation of Crate’s all-tube amplifiers. With dual 6L6 fixed biased output tubes, this bad refrigerator produces the sort of sparkling cleans and warm, thick overdrive that can only come from tubes pushed to their limit. It pumps 50 watts through a single 12-inch speaker, creating a muscular low end perfect for club gigs and recording sessions. Presence control, spring reverb and foot-switchable boost make sure you can dial in your custom tone from anywhere. Lesser amps will blow their fuses in fear when they see you plugging into a V50-112.
Features
50 watts RMS
Class AB, all tube circuitry
1 x 12 in. speaker
Two channels
2 x 6L6 output tubes, fixed bias
Spring reverb
Technical Info
Output Power Rating: 50 W rms @ 5% THD, 8 ohm load, 120 VAC
Signal-to-Noise Ratio: 70 dB, Typical (Clean Ch only)
Gain:
-Overdrive Ch 98 dB, all controls @ 10
-Clean Ch 58 dB, all controls @ 10
EQ:
-Treble: 12 dB range @ 6 kHz
-Middle: 10 dB range @ 1 kHz
-Bass: 8 dB range @ 150 Hz
Boost: 10 dB @ 900 Hz
Presence: 8 dB range @ 10 kHz
Speaker Specs: 12 in., 50 W, 8 ohm, 1.75 in. voice coil diameter, 30 oz magnet
Extension Speaker: 8 ohms minimum nominal impedance
Preamp Tubes: (3) 12AX7A
Power Tubes: (2) 6L6GC
Power Requirements:
-90-132 VAC, 60 Hz, 150 VA
-220-240 VAC, 50 Hz, 150 VA
Size (H x W x D): 19.0 in/48.3 cm x 24.0 in/61.0 cm x 11.0 in/27.9 cm
Weight: 48.5 lb/22.0 kg
