Audio Inputs:
- Type: RF-filtered, servo balanced XLR and 1/4 in. TRS connectors
- Impedance: 40k ohms balanced and unbalanced
- Maximum Input Level: +21 dBu balanced and unbalanced
Audio Outputs:
- Type: Servo-balanced XLR and 1/4 in. TRS connectors
- Subwoofer Out: Balanced XLR connector
- Crossover Frequency: variable, 30-200Hz
System Specifications:
- Frequency Response: 10Hz to 200kHz, +/- 3 dB
- Signal to Noise Ratio: 22 Hz to 22 kHz > 94 dB @+4 dBu
- THD: Typical 0.006% @ +4 dBu, 1 kHz, Gain 1
- Crosstalk: Typical 65 dB @ 1 kHz
Roll-Off Filtersection:
- Type: 12 dB/octave, Butterworth
- Input: variable (-15 dB to +15 dB)
- Low Cut: switchable, cutoff @ 25 Hz
Graphic Equalizer:
- Type: Analog 15-band equalizer
- Frequency Range: 20 Hz to 16 kHz in 15 (ISO frequencies)
- Bandwidth: 2/3 octave
- Control Range: +/-6 dB or +/-12 dB (switchable)
Dimensions (H x W x D): 1-3/4 x 19 x 8-3/8 in.
Weight: 4.74 lbs
- New
- Shipping Weight: 7.2 lbs
-
Shipping Dimensions:
21 x
12 x
4 in
- Warehouse Resealed
- Shipping Weight: 7.2 lbs
-
Shipping Dimensions:
21 x
12 x
4 in
- Warehouse Select
- Shipping Weight: 7.2 lbs
-
Shipping Dimensions:
21 x
12 x
4 in
