Product Description
Intel Core 2 Duo processor
Powered by the latest generation of Intel's mobile processors plus a larger L2 cache, the new MacBook Pro is up to 39% faster than the previous MacBook Pro generation.
Built-in iSight Camera
Setting up a video conference is easy and fast with the included iChat AV and built-in iSight. Host a face-to-face dialogue with up to three other colleagues — no cords or cameras to carry around.
The MacBook Pro advantage
FireWire 800, DVI, optical digital audio, ExpressCard/34, and Gigabit Ethernet deliver high-bandwidth digital connections to your peripheral devices.
Front Row & Apple Remote
Present your photos, videos, and even Keynote presentations to an audience and control the display from up to 30 feet away.
Designed for life on the road
Dozens of unique innovations — such as a magnetic power cord, the illuminated keyboard with ambient light sensor, and scrolling trackpad — put the MacBook Pro in a class by itself.
MacBook Pro At a Glance
15.4- or 17-inch widescreen display
Up to 2.16GHz Intel Core 2 Duo
667MHz frontside bus and main memory
PCI Express architecture
Up to 120GB Serial ATA hard drive
ATI Mobility Radeon X1600 with up to 256MB memory on 16-lane PCI Express
ExpressCard/34 slot
Dual-link DVI, VGA adapter included
FireWire 400, FireWire 800 (17-inch only), and USB 2.0 ports
Optical digital and analog audio I/O, built-in microphone and stereo speakers
Slot-loading SuperDrive
Illuminated keyboard, Scrolling TrackPad
Built-in AirPort Extreme (802.11g), Bluetooth 2.0+EDR, and Gigabit Ethernet
Mac OS X Tiger with iLife '06 featuring iWeb, iWork '06 trial, and more
MagSafe Power Adapter
1. AirPort Extreme uses the 802.11g wireless standard. Accessing the wireless network requires an AirPort- or AirPort Extreme-enabled computer or Wi-Fi-certified 802.11b or 802.11g computer. Achieving data rates of 54 Mbps requires that all users have an AirPort Extreme- or Wi-Fi-certified 802.11g-enabled computer and connect to an AirPort Extreme Base Station. If a user of a Wi-Fi-certified 802.11b product joins the network, that user will get up to 11 Mbps, and AirPort Extreme and Wi-Fi-certified 802.11g users will get less than 54 Mbps. Actual speed will vary based on range, connection rate, site conditions, size of network, and other factors.
2. Wireless Internet access requires AirPort Card or AirPort Extreme Card; AirPort Base Station, AirPort Extreme Base Station or other wireless access point; and Internet access (fees may apply). Some ISPs are not currently compatible with AirPort and AirPort Extreme. Range may vary with site conditions.
zZounds is an authorized dealer of
Apple products.
In the box
MacBook Pro
85W MagSafe Power Adapter, AC wall plug and power cord
Lithium-polymer battery
Apple Remote
DVI to VGA adapter
Install/restore DVDs
Printed and electronic documentation
Processor and Memory
15-inch MacBook Pro:
-- Intel 2.16GHz Intel Core 2 Duo processor, 4MB shared L2 cache running 1:1 with processor speed
-- 512MB (single SODIMM) of PC2-5300 (667MHz) DDR2 memory on 2.0GHz configuration; and 1GB (single SODIMM) on 2.16GHz configuration; two SODIMM slots support up to 2GB
-- 667MHz frontside bus
Expansion
15-inch MacBook Pro
-- One FireWire 400 port at up to 400 Mbps
-- Two 480-Mbps USB 2.0 ports
-- ExpressCard/34 slot
Security
Kensington cable lock slot
Battery and power
15-inch MacBook Pro
-- 60-watt-hour lithium-polymer battery (with integrated charge indicator LEDs) providing up to 4.5 hours of battery life(1)
85W MagSafe Power Adapter with cable management system
MagSafe Power Adapter port
Battery
Communications
Built-in 54-Mbps AirPort Extreme wireless networking (802.11g standard) (2).
Built-in Bluetooth 2.0+EDR (Enhanced Data Rate)
Built-in 10/100/1000BASE-T Gigabit Ethernet (RJ-45 connector)
Audio
Combined optical digital input/audio line in (minijack)
Combined optical digital output/headphone out (minijack)
Built-in stereo speakers
Internal omnidirectional microphone (located under left speaker grille)
Video and graphics support
15-inch MacBook Pro
-- ATI Mobility Radeon X1600 graphics processor, dual link DVI support, 128MB of GDDR3 on 2.0GHz configuration. 256MB GDDR3 on 2.16GHz configuration
Dual display and video mirroring: Simultaneously supports full native resolution on the built-in display and up to 2560 by 1600 pixels on an external display, both at millions of colors
DVI output port
VGA output using included DVI to VGA adapter
Built-in iSight camera
Storage
15-inch MacBook Pro
-- 100GB 5400-rpm Serial ATA hard drive on 2.16GHz configuration. Optional 100GB 7200-rpm or 120GB 5400-rpm hard drives.
-- 4x Slot-loading SuperDrive (DVD�RW/CD-RW)
+ Maximum Write: 4x DVD-R, DVD+R, DVD+RW, and DVD-RW; 24x CD-R; 10x CD-RW
+ Maximum Read: 8x DVD-ROM; 6x DVD-ROM (double layer DVD-9), DVD-R, DVD+R, DVD+RW, DVD-RW; 4x DVD+R (double layered) and DVD-R (double layered); 24x CD
Display
15-inch MacBook Pro
-- 15.4-inch (diagonal) TFT display, support for millions of colors
-- Supported resolutions: 1440 by 900 (native), 1280 by 800, 1152 by 720, 1024 by 640, and 800 by 500 at 16:10 aspect ratio; 1024 by 768, 800 by 600, and 640 by 480 at 4:3 aspect ratio; 1024 by 768, 800 by 600, and 640 by 480 at 4:3 aspect ratio stretched; 720 by 480 at 3:2 aspect ratio, 720 by 480 at 3:2 aspect ratio stretched
Keyboard and trackpad
Built-in full-size keyboard with 78 (U.S.) or 79 (ISO) keys, including 12 function keys, 4 arrow keys (inverted "T" arrangement), and embedded numeric keypad
-- Backlit keyboard with ambient light sensors for automatic adjustment of keyboard illumination and screen brightness
Solid-state scrolling Trackpad for precise cursor control; supports two finger scrolling, tap, double-tap, and drag capabilities
Apple Remote included
Electrical and environmental requirements
Meets ENERGY STAR requirements
Line voltage: 100V to 240V AC
Frequency: 50Hz to 60Hz
DC input: 18.5 Vdc, 4.6 A max.
Operating temperature: 50 degrees to 95 degrees F (10 degrees to 35 degrees C)
Storage temperature: -13 degrees to 113 degrees F (-24 degrees to 45 degrees C)
Relative humidity: 0% to 90% noncondensing
Maximum operating altitude: 10,000 feet
Maximum storage altitude: 15,000 feet
Maximum shipping altitude: 35,000 feet
Size and weight
15-inch MacBook Pro
-- Height: 1.0 inch (2.59 cm)
-- Width: 14.1 inches (35.7 cm)
-- Depth: 9.6 inches (24.3 cm)
-- Weight: 5.6 pounds (2.54 kg) with battery and optical drive installed (4)
Software
Mac OS X v10.4 Tiger (includes Spotlight, Dashboard, Mail, iChat AV, Safari, Address Book, QuickTime, iCal, DVD Player, Xcode Developer Tools)
Universal iLife '06 (includes iTunes, iPhoto, iMovie HD, iDVD, iWeb, GarageBand), Microsoft Office 2004 for Mac Test Drive, iWork '06 (30-day trial), Comic Life, FileMaker Pro trial, Omni Outliner
Photo Booth
Front Row
Configuration
Processor: 2.16GHz Intel Core 2 Duo
Memory: 1GB (single SODIMM) 667MHz DDR2 SDRAM (PC2-5300)
Display: 15.4-inch (diagonal), 1440 x 900 resolution, TFT widescreen
PCI Express Graphics: ATI Mobility Radeon X1600 with 256MB of GDDR3 SDRAM and dual-link DVI
Video: Built-in iSight Camera, DVI, VGA (DVI to VGA adapter included)
Audio: Combined optical digital input/audio line in, combined optical digital output/headphone out, stereo speakers, microphone
Hard disk drive (3): 100GB Serial ATA/100; 5400 rpm
Slot-loading optical drive: 4x SuperDrive (DVD�RW/CD-RW)
Ethernet: Built-in 10/100/1000BASE-T (Gigabit)
Wireless (2): Built-in 54-Mbps AirPort Extreme (802.11g); built-in Bluetooth 2.0+EDR
Modem: Apple USB Modem (sold separately)
Input: Apple Remote; full-size, illuminated keyboard with ambient light sensor; Scrolling Trackpad
Expansion: One FireWire 400, two USB 2.0 ports, and ExpressCard/34 slot
Weight: 5.6 pounds
Footprint: 14.1 x 9.6 inches
Thickness: 1.0 inch (2.59 cm)
Video accessories: DVI to VGA adapter included (other adapters sold separately)
Hardware accessories: 85W MagSafe Power Adapter, AC wall plug, power cord, lithium-polymer battery
Limited warranty and service: Your MacBook Pro comes with 90 days of telephone support and a one-year limited warranty. For more information, visit Apple support or call 800-823-2775.
Apple Warranty
If you have additional warranty questions,
please call the manufacturer at 800-MY-APPLE
