The term 'high-fidelity' has been often misused from its original meaning of true, realistic sound. So when we say these enclosures are hi-fi, we mean real 'high-fidelity' sound. Pro Series cabinets are designed to accurate reproduce the output signal of the amplifier at OSHA disturbing levels.
At the heart of the enclosures are the premium American-made cast-frame drivers. Large edgewound aluminum voice coils, vented back plates, and oversized ceramic magnets all add to the premium tone and fast response.
These cabinets are not only made for the stage; they're made for the transport between stages. The 13-ply void-free Baltic birch cabinets are heavily braced to add rigidity. Corners and edges are protected with shock-absorbing PVC armor.
Technical Info
Dimensions: 30 x 26 x 19 in.
Weight: 128 lbs.
Component 1: Magnet Weight: 56 oz.
Component 1: Size: 4x10 in. Cast
Component 1: Voice Coil: 2.5 in.
Component 2: Magnet Weight: 10 oz.
Component 2: Size: Horn/Driver
Component 2: Voice Coil: 1 in.
Crossover Frequency: 4kHz
Frequency Response (-3 dB): 33-18KHz
Maximum SPL: 124 dB
Nominal Impedance: 4 ohms
Program Handling: 1200 Watts
RMS Handling: 600 Watts
Sensitivity: 96dB
Usable Low Frequency (-10dB): 29Hz
