Series: Deluxe Series
Body: Alder (Precision Bass Body)
Neck: Maple Jazz Bass neck, Modern 'C' Shape, Satin polyurethane finish
Fingerboard: Rosewood, 9.5-inch Radius/241 mm
Number of Frets: 20 Medium Jumbo frets
Scale Length: 34-inch (864 mm)
Width @ Nut: 1.50-inch (38mm)
Machine Heads: Standard
Bridge: American Vintage Precision Bass
Pickguard: Gold Anodized Aluminum Precision Bass Pickguard
1 Standard Alnico Split Single-Coil Precision Bass Pickup (Mid)
1 Dual-Coil Ceramic Jazz Bass Pickup (Bridge)
Pickup Switching: Pan Pot
Controls: Master Volume, Pan Pot, 3-Band Active EQ with:
Treble Boost/Cut: +/- 10 db @ 8kHz, a shift in the cut frequency, and about a 2dB slope per octave.
Mid Boost/Cut: +10dB, -15dB @ 500Hz, and a wide band slope.
Bass Boost/Cut: +/- 12 db @ 40 Hz, with a 4dB slope per octave.
Strings: Fender Super Bass 7250ML, NPS,
Gauges: .045, .065, .080, .100,
Side Mounted Jack
US Electronic Components
Accessories: Deluxe Gig Bag
Wrench Sizes: Truss Rod 3/16 in.
- Weight, Dimensions, and Manufacturer Part Numbers
Manufacturer Part Number (MPN):
