zZounds Gear Experts Say...
Hear everything you need to hear onstage with the Yamaha DHR12M, a powered speaker with 1000 watts of Class D power and a coincident driver design.

The Yamaha DHR12M powered loudspeaker features a custom Coaxial Driver design that provides near perfect phase response, making it one of the most accurate floor monitors in its class. With 1000 Watts of Class D power, up to 129dB SPL is possible. A strong steel grille and rugged plywood cabinet will stand up to well to stage use.

Features:

- 1.75" precision HF compression driver coaxially mounted
- Strong plywood cabinets with a tough polyurea coating
- Ultra-Precise 48bit (76bit Accumulator) DSP processing
- Employs FIR-X tuning to optimize time alignment, frequency and phase response for the crossover network
- D-CONTOUR intelligent multi-band dynamics processor
- DSP protection for maximum output and component longevity
- Custom designed transducers
- High-Efficiency Class-D Amplifiers
- Onboard 2-Ch Mixer

- Speaker Type: 2-way bi-amp powered loudspeaker, bass-reflex
- Frequency Response (-10dB): 55Hz - 20kHz
- Horizontal Coverage Angle: 90°
- Vertical Coverage Angle: 60°
- LF Driver: 12" cone, 2.5" voice coil, ferrite magnet
- HF Driver: 1.75" coaxial compression driver, 1" throat, ferrite magnet
- Crossover Frequency: 1.8kHz (FIR-X tuning™ linear phase FIR filter)
- Amplifier Type: Class-D bi-amplified
- Amplifier Power (LF): 800W
- Amplifier Power (HF): 200W
- Maximum SPL: 129dB SPL (measured peak, IEC noise @1m)
- Input Connectors: INPUT1: Combo XLR/1/4" x1, INPUT2: Combo XLR/1/4" x1 + RCA pin x2 (unbalanced)
- Output Connectors: XLR3-32 x1 (CH1 parallel through or CH1+CH2 mix)
- Power Supply: IEC AC inlet, 100V-240V, 50/60Hz
- Power Consumption: 74W (1/8 power), 18W (idle)
- Enclosure Type: Bass-reflex ported
- Enclosure Material: Plywood
- Finish: Durable polyurea coating, black
- Grille: Steel grille
- Mounting Options: Floor monitor (57° angle), pole socket (Φ35mm x1), side handle x1

Dimensions and Weight in Packaging

Base Item

  • Shipping Weight: 50.25 lbs
  • Shipping Dimensions: 22 x 22 x 18 in
  • Manufacturer Part Number (MPN): DHR12M

Open Box (Like New)

  • Shipping Weight: 49.85 lbs
  • Shipping Dimensions: 25 x 18 x 17 in
  • Manufacturer Part Number (MPN): DHR12M
