Phenyx Pro PTM-10-2B UHF Stereo Wireless In-Ear Monitor System
zZounds Gear Experts Say...
With two bodypack receivers included, the Phenyx Pro PTM-10-2B system gives you UHF in-ear monitoring with selectable frequencies at an awesome price.
Overview
Available here in the PTM-10-2B configuration with 2 bodypack receivers, Phenyx Pro's PTM-10 wireless IEM system emerges as an ideal stage partner for discerning music enthusiasts and professional performers. It provides an immersive stereo sound monitoring experience to let you hear the difference. With multiple customizable functions, it empowers you to fine-tune your monitor mix.
Note: The PTM-10 transmitter is capable of sending a single monitor mix. Each bodypack receiver connected to this transmitter receives the same, unified monitor mix.
- Exceptional, pure, distortion-free sound performance with very low latency
- The PAD button lowers the input gain to prevent loud input sources from overloading and clipping the preamplifier
- The powerful receiver features multiple practical functions, including stereo/mono selection, balance, equalizer, limiter, and lock functions
- Quick IR sync and one-touch frequency selection for fuss-free operation
- The adapter cord tie-off for manageable cabling
- Included metal rackmount kit for the professional workflow
- The black PVC carrying case protects the system while in transit
- Up to 160ft/50m of free operation range
- 89 adjustable UHF frequencies in 500MHz/900MHz range for multi-set operation:
-- 905 – 925 MHz (89 frequencies)
-- 555 - 575 MHz (89 frequencies)
- PTM-10 supports multi-set operation with up to 5 systems in the 900 MHz band… read more and up to 4 systems in the 500 MHz band
read less
Note: The PTM-10 transmitter is capable of sending a single monitor mix. Each bodypack receiver connected to this transmitter receives the same, unified monitor mix.
Features:
- Immersive stereo monitoring experience with up to 93% sound separation- Exceptional, pure, distortion-free sound performance with very low latency
- The PAD button lowers the input gain to prevent loud input sources from overloading and clipping the preamplifier
- The powerful receiver features multiple practical functions, including stereo/mono selection, balance, equalizer, limiter, and lock functions
- Quick IR sync and one-touch frequency selection for fuss-free operation
- The adapter cord tie-off for manageable cabling
- Included metal rackmount kit for the professional workflow
- The black PVC carrying case protects the system while in transit
- Up to 160ft/50m of free operation range
- 89 adjustable UHF frequencies in 500MHz/900MHz range for multi-set operation:
-- 905 – 925 MHz (89 frequencies)
-- 555 - 575 MHz (89 frequencies)
- PTM-10 supports multi-set operation with up to 5 systems in the 900 MHz band… read more and up to 4 systems in the 500 MHz band
Specs
- System Frequency Range: 905 - 925 MHz or 555 - 575 MHz
- System Transmitter output level: 10dBm
- System Dynamic range: >105dBm
- System Frequency response: 60Hz - 16kHz
- System Stereo separation: >40dBm
- System Working distance: 50m/164ft
- Transmitter Max audio input level: +6dBV
- Transmitter Gain adjustment range: 40dB
- Transmitter Input impedance: 6.8kO
- Transmitter Power requirement: INPUT: AC 110V - 240V, 50/60 Hz; OUTPUT:DC 13.5V, 500mA
- Bodypack Audio input level: 100mV
- Bodypack Image rejection: >65dB
- Bodypack Battery life: 8 hours
- System Transmitter output level: 10dBm
- System Dynamic range: >105dBm
- System Frequency response: 60Hz - 16kHz
- System Stereo separation: >40dBm
- System Working distance: 50m/164ft
- Transmitter Max audio input level: +6dBV
- Transmitter Gain adjustment range: 40dB
- Transmitter Input impedance: 6.8kO
- Transmitter Power requirement: INPUT: AC 110V - 240V, 50/60 Hz; OUTPUT:DC 13.5V, 500mA
- Bodypack Audio input level: 100mV
- Bodypack Image rejection: >65dB
- Bodypack Battery life: 8 hours
Dimensions and Weight in Packaging
555 - 575 MHz, PTM-10-2B-500
- Shipping Weight: 5.93 lbs
- Shipping Dimensions: 15 x 14 x 4 in
- Manufacturer Part Number (MPN): PTM-10-2B 500
905 - 925 MHz, PTM-10-2B-900
- Shipping Weight: 6.1 lbs
- Shipping Dimensions: 15 x 14 x 4 in
- Manufacturer Part Number (MPN): PTM-10-2B 900
Documents and Manuals
For support or warranty questions, please contact the manufacturer:
Email: support@phenyxpro.com
Web: https://support.phenyxpro.com
Email: support@phenyxpro.com
Web: https://support.phenyxpro.com
