This product is no longer available at zZounds.

(In most cases, a product is unavailable because it has been discontinued by its manufacturer.)

Tannoy Reveal Active Powered Monitor

1 in. tweeter. 6.5 in. long-throw bass unit. Two 50-watt amplifiers. 62 People rated this product:

Rate and Review This Product

Roll Over to Enlarge

Main

overview specifications

Manufacturer's Description for Tannoy Reveal Active Powered Monitor

Reveal active monitors are distinctive playback monitors providing sonic excellence at a budget price level. They each feature a 1 in. soft dome tweeter is matched with a 6.5 in. long-throw bass unit, two 50-watt amplifiers, and electronic crossover. Both drive units are magnetically shielded, allowing operation close to video monitors. Designed for budget conscious project studios and as a playback monitor in larger rooms. zZounds is an authorized dealer of Tannoy products.

Inputs: 32 k ohm balanced on combined XLR/jack

Input Sensitivity: 0.775Vrms (0dBu)

Sensitivity: 0 dBu

Frequency Response: 62 Hz - 20kHz

Peak SPL (pair @ 1m): 114 dB

Built-in Amplifier (Power RMS): LF channel (4-ohm load) 50 W rms

RH channel (4 ohm load): 50 W rms

High Frequency Driver: Tannoy shielded 1 in. soft dome tweeter

Low Frequency Driver: Tannoy shielded 6.5 in. bass driver

Dispersion: 90 degrees

Crossover Frequency: 3 kHz

Enclosure Type: Optimized bass-reflex

Volume: 12 liters

Dimensions: 340 x 210 x 260mm (13.38 x 8.27 x 10.24 in.)

Weight: 8.5 kg (18.7 lbs.)

Finish: Azure Blue satin front, Gray suedette vinyl sides and back

Our extended 30-Day 100% Satisfaction Guarantee applies on this product. Buy it, and if it isn't just right for you, return it!

Our Return Policy

Payment Options

Purchase Orders

What Our Customers Are Saying About zZounds "When I shop with zZounds I know I'm not getting ripped off. The customer service staff takes great care to make sure I'm buying the right piece of equipment not the most expensive piece of equipment." - customer on February 4th, 2012

Customer Reviews

4.5 out of 5 (62 ratings) Rate and Review This Product

Read 2 Tannoy Reveal Active Powered Monitor Reviews

"best for the price"

Sound: Extremly good for the price. Might lack some detail in the lower frequencies, but overall, a very very good sound. Quality: very sturdy. its loudspeakers for god sake! :) Value: better than most of the monitors in this segment. The Wow Factor: cosmeticly they looks pretty good i must say! Overall: Correct me if Im wrong, but this is the best monitors you can get in this price-segment.

Style of Music: hiphop

Did you find this review helpful?

Thanks for your opinion!

close [x]

Thank you. Your vote has been counted. Could you briefly tell us why the review was or was not helpful?

"Super Speakers"

Sound: Clarity Feature: No volume control Overall: Best sounding speakers I've ever heard.
