TC Helicon Quintet Harmony Reverb Vocal Processor

TC Helicon Quintet Harmony Reverb Vocal Processor
Quintet combines TC Helicon's renowned harmony algorithms and TC Electronic's famous Reverb technology, providing the affordable key to great live and recorded vocals. Features include 4 harmony voices plus lead voice double-tracking, a high-quality mic preamp with an XLR mic input, and 24-bit processing with a S/PDIF output. Drawing upon the TC Helicon heritage, Quintet is fast and easy to use. It supports simple editing and control of all harmony and effect parameters either from the front panel or via MIDI. Quintet is a songwriter's best friend, a live performers' dream and the secret weapon for every home project studio.

Features

High-quality mic preamp

4 harmony voices plus lead voice double-tracking

Timing and Pitch Humanization

TC Electronic Reverb

A/B program switching for live performance

24-bit processing with 44.1/48 kHz S/PDIF output

MIDI control

Technical Info

Specifications

Digital Outputs
Connectors: RCA Phono (S/PDIF)
Formats: S/PDIF (24 bit), EIAJ CP-340, IEC 958
Sample Rates: 44.1 kHz, 48 kHz
Frequency Response: DO DC to 22/23.9 kHz ± 0.01 dB @ 44.1/48 kHz

Analog Inputs
Connectors, balanced: Mic.: XLR, Line: 1/4 in. phone jack
Impedance
Balanced/Unbalanced Mic.: 3.6/1.8 kOhm
Line: 21/13 kOhm
Line Input Level @ 0 dBFS: +24 dBu to 0 dBu
Line Sensitivity @ 12 dB headroom: -12 dBu to +12 dBu
Mic. Input Level @ 0 dBFS (Pad Off/On): -14 dBu/+6 dBu to -51 dBu/-31 dBu
Mic. Sensitivity @ 12 dB headroom (Pad Off/On): -26 dBu/-6 dBu to -63 dBu/-43 dBu
Line, Mic. @ Min. gain, Dynamic Range: > +92 dB, 20 Hz - 20 kHz
NF/Vi @ Max. micamp. gain, Rg = 200 Ohm: < +2 dB / -127.4 dBu
THD: < -100 dB (0,001 %) @ 1 kHz
Line Frequency Response: +0/-0.1 dB, 20 Hz to 20 kHz
Mic. Frequency Response, max gain: -1.5 dB @ 40 Hz, +0/-0.1 dB (200 Hz to 20 kHz)
Crosstalk: < -85 dB, 20 Hz to 20 kHz
A to D Conversion: 24 bit, 128 x oversampling bitstream
A to D Delay: 0.65/0.70 ms @ 48/44.1 kHz

Analog Outputs
D to A Conversion: 24 bit, 128 x oversampling bitstream
D to A Delay: 0.63/0.68 ms @ 48/44.1 kHz
Connectors, balanced: 1/4 in. phone jack
Output Impedance: 40 Ohm
Max. Output Level (Balanced/Unbalanced): +20 dBu/+14 dBu, R-load >= 1200 Ohm
Output Range: Variable up to +20 dBu
Dynamic Range: > +104 dB, 20 Hz to 20 kHz
THD: <-98 dB (0.0013 %) @ 1 kHz
Frequency Response: 20 Hz to 20 kHz, +0/-0.3 dB
Crosstalk: <-100 dB, 20 Hz to 20 kHz
EMC
Complies with EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B
Safety
Certified to IEC 65, EN 60065, UL6500 and CSA E60065 CSA FILE #LR108093

Environment
Operating Temperature: 32° F to 122° F (0° C to 50° C)
Storage Temperature: -22° F to 167° F (-30° C to 70° C)
Humidity: Max. 90 % non-condensing

Control Interface
MIDI: In/Out/Thru: 5 Pin DIN
Pedal: 1/4 in. phone jack

Supplementary
Display: 1x16 backlit LCD
Dimensions: 19 in. x 1.75 in. x 8.2 in. (483 x 44 x 195 mm)
Weight: 4.1 lb. (1.85 kg)
Mains Voltage: 100 to 240 VAC, 50 to 60 Hz (auto-select)
Power Consumption: <15 W
Warranty: Parts and labor 1 year
Note - Due to continuous development and standardization all specifications are subject to change without notice.
