Evolution 100 Series makes any stage performance possible. Ideal for any musical style, from extreme rock to sensitive ballads, and performers and presenters of any kind.
System Includes: EM100 Receiver, SKP100 Plug-On Transmitter, MD835 Microphone Capsule
Features
Professional UHF transmission quality
Four switchable preset memory locations (using any of the 1280 available frequencies)
Diversity receiver
High-quality metal microphone construction
Choice of dynamic or condenser microphone capsules
Like all evolution wireless systems, the rugged metal housing of evolution 100 Series ensures it can withstand the rigors of life on the road. evolution 100 Series' tough build quality comes with a whole lot moreá great handling, simple, easy-to-set controls, and a design that reflects its stature as a serious professional instrument. Evolution 100 Series transmitters and receivers offer four pre-selected switchable UHF frequencies for simple set-up and operation; while additional channels can be selected and set manually in increments of 25 kHz for extra versatility.
Technical Info
System Includes: EM100 Receiver, SKP100 Plug-On Transmitter, MD835 Microphone Capsule
Modulation: wideband FM
Frequency ranges: 518-550, 630-662, 740-772, 790-822, 838-879 MHz
Switchable frequencies: 1,280
Presets: 4
Switching bandwidth: 32 MHz
Peak deviation: ± 48 kHz
Compander: Sennheiser HDX
AF Frequency Response: 60-18,000 Hz
Signal-to-noise ratio: > 110 dB (A)
THD (1 kHz): < 0.9 %
In compliance with ETS 300 422, ETS 300 445, CE, FCC
System case (Dimensions/Weight): 380 x 370 x 70mm/approximately 3 kg
EM100 Receiver
Receiver type: True Diversity
Antenna inputs: 2 BNC sockets, 50 ohms
AF outputs: 1/4 in. jack
Max. output level: balanced: + 10 dBu,unbalanced: + 4 dBu
Power supply: 10.5 - 16 V DC
Dimensions: 212 x 145 x 38mm
Weight: approximately 1,100 g
Handheld Transmitter
RF output power: typ. 30 mW
Power supply: 9 V alkaline-manganese, 6LR61
Operating time: > 8 h
Dimensions: ø 50 mm, l = 225 mm
Weight: approximately 450 g
MD 835 Microphone Capsule
Transducer: dynamic
Sensitivity: 1.5 mV/Pa
Max. SPL: 150 dB
Pick-up pattern: cardioid
