Point Source Audio Pocket Portable Wireless Microphone System

Manufacturer's Description for Point Source Audio Pocket Portable Wireless Microphone System

Consumer Alert
Most users do not need a license to operate this wireless microphone system. Nevertheless, operating this microphone system without a license is subject to certain restrictions: the system may not cause harmful interference; it must operate at a low power level (not in excess of 50 milliwatts); and it has no protection from interference received from any other device. Purchasers should also be aware that the FCC is currently evaluating use of wireless microphone systems, and these rules are subject to change. For more information, call the FCC at 1-888-CALL-FCC (TTY: 1-888-TELL-FCC) or visit the FCC’s wireless microphone website at www.fcc.gov/cgb/wirelessmicrophones

NOTE: None of the wireless systems we carry are capable of violating the FCC guidelines stated above. We are presenting this information as a matter of legally required disclosure.

Super fast to set-up and ultra light, the Point Source AudioStream--with your choice of a PSA wireless microphone headset--is your go-to solution for an easy and elegant wireless microphone system anywhere, anytime. The AudioStream is fully optimized for all Point Source Audio microphone headsets and earbuds giving you the versatility and value to have a wireless microphone or in-ear monitoring solution in one--for all types of sound system or computer applications.

Features
- Meets FCC requirements by avoiding the UHF channels off limit to wireless microphones. No radio frequency (RF) interference, signal loss, crackle inherent with UHF/VHF systems, or AC hum.

- Continuously and automatically selects among 40 available channels. Allows 10 systems (transmitter to receiver) to operate at the same time.

- Receiver instantly repairs lost data due to bursts of interference.

- Designed specifically for audio to non-compete with wireless networks and other wireless devices operating in the IEEE 802.11 networks.

- Record to your computer or play music with a wireless link.

- Convert from a microphone to a monitoring solution and back with a simple swap of the accessories. Enjoy two systems in one.

- Sets-up in seconds... no knobs to tweak or antennas to adjust. And no spectrum analyzer needed.

- Each unit only weighs 1 oz. (with the battery!)

- 100 feet range optimal for numerous small area venues from houses of worship to your home or office.

- Transmitter synchs up to eight (8) different receivers with a simple press of the Link button. No more removing, swapping or disconnecting cables.

- Four (4) Power Options: AA battery adapter (optional) provides up to 13 hours of operation, Rechargeable battery provides standard operating time of 4 ~ 6 hours, USB bus power charges from your MAC or PC, AC power adapter for continuous operation.

- Included Hard Shell Carrying Case protects your wireless system and all accessories in one place for instant access

Included with the AudioStream Wireless Microphone System is one of the most flexible microphone headsets on the market. Each AudioStream can be paired with a microphone headset or earbuds for interchangeable applications. The wireless microphone headset options can be worn in up to four (4) different configurations. The headset microphones are available for performance requirements ranging from basic speech optimization to high energy vocals. Fully optimized for applications up to 100 feet of range, the AudioStream Wireless Microphone system is ideal for:

- Small Houses of Worship
- Night clubs
- Professional speakers
- Acoustic music instruments
- Community theaters
- School classrooms
- Video cameras
- Home or office

About CO3 Headset Microphone
The CO3 Series Microphone is our entry-level ear-worn microphone designed for speech reinforcement for church liturgy, lecturing, and other applications that require good quality vocal pick up in a hands-free environment. It has an omni-directional polar pattern which allows a full 360 degree pick up of sound providing a natural blend of voice and ambience. The design of the CO-3 series lends itself to reduced speech produced popping sounds and voice overloads in close mic applications, and is less susceptible to wind and clothing noise than lavaliere style microphones. Its distinguishing clarity in close talk operation and excellent gain before feedback make it suitable for applications where higher degrees of speech intelligibility are desired.

CO3 Features
- Ultra low profile
- Increased gain before feedback
- Stationary left-ear boom - no adjustments necessary
- Available in beige
- Converts to dual earset - left ear

About CO5 Headset Microphone
The CO5 Series Microphone is a durable ear-worn microphone with flexible boom designed for vocal reinforcement for church liturgy, singing, aerobics instruction, lecturing, sports-casting and other applications that require high quality vocal pick up in a hands-free environment. Its omni-directional polar pattern allows a full 360 degree pick up of sound providing a natural blend of voice and ambience. The design of the CO5 series lends itself to reduced speech produced popping sounds and voice overloads in close mic applications. It is also less susceptible to wind and clothing noise than lavaliere style microphones. Its distinguishing clarity in close-talk operation and excellent gain before feedback make it suitable for applications where higher degrees of speech intelligibility are desired.

CO5 Features
- Ultra low profile
- Optimized for clarity
- Increased gain before feedback
- Flexible left or right ear design
- Durable construction
- Converts to dual earset - left or right ear

About CO7 Headset Microphone
The CO7 is a durable ear-worn microphone constructed to suit the most demanding commercial and professional applications. The microphone can be worn either over the left or right ear, or as a dual earset option giving users four (4) ways to wear it. It's configured to plug into almost any wireless microphone system; or can be hard-wired direct to the input of a mixing console. The product is ideal for performance grade audio quality typically only experienced using a larger format microphone.

CO7 Features
- Ultra low profile
- 135 dB of sound pressure
- Optimal gain before feedback
- Unbreakable Boom - bendable to 360 degrees!
- Flexible left or right ear design
- Available in colors beige, tan and black
- Converts to earset microphone- dual ear option

What's in the Box?
- COX Microphone Headset (choose CO3, CO5 or CO7)
- AudioStream Transmitter and Receiver
- One (1) 1/8 inch to 1/4 inch TRS Stereo Cables
- One (1) 1/8 inch to 1/4 inch TRS Mono Cables
- USB Power Cable
- Universal USB Power Adapter
- Hard Shell Carrying Case
- User Guide zZounds is an authorized dealer of Point Source Audio products.

Specifications
Transmission Format: 2.4GHz Digital Wireless

Bit Rate: 16-bit , 48 kHz Stereo CD Audio Quality (Uncompressed Audio)

Frequency Response: 15Hz -20kHz

Frequency Selection: Auto (40 channels)

Connectors: 1/8 inch TRS Stereo

Input impedance: 3.3K ohm

Max input level: 1V RMS

Output impedance: < 10 ohm

Max Output level: 700mV RMS

Stereo Line-in NR: > 89 dB

Stereo/Mono MIC-in NR: > 84 dB

Distortion: 0.12 % THD

Antenna: Two Internal Antennas

Wireless Range: > 100 Feet (May not be dependent on line of sight) (Range may vary due to local conditions)

Input Support: Earphones, PSA stereo and mono microphones

Audio Signal Routing: One Transmitter to eight (8) Receivers

Rechargeable Battery Life: > 4 ~ 6 hours (10~13 Hours w/ optional AA battery booster)

Power Input: 5V DC, 500 mA (USB Bus Power)

Maximum Units Operating at Same Time: 10

Mounting: Metal Belt Clip

Dimensions: 1.2 x 0.6 x 3.34 in.

Weight: 0.068 pounds (1.08 oz.)
