Phonic PowerPod 740 7-Channel Powered Mixer
4 types of digital effects. 7 input channels. 3-band EQ on each input channel.
Loading...
Our 30-Day 100% Satisfaction Guarantee applies on this item. Buy it, and if it isn't just right for you, return it!
Description
Since its introduction in 1998, the Powerpod740 (previously called Powerpod7) has proved to be an excellent choice for musicians and venues alike. The Powerpod740 offers power and flexibility that can withstand 'life on the road'. Two separate 200 watt amplifiers enable the user to configure the output in three different ways, either Main + Main, Main + Monitor or Main only (Bridged operation, 400W). The Powerpod740 has all the patching necessary to connect you to more amplifiers and an external processor or to accept more inputs via another mixer when circumstances require.
Features:
Built-in 200W + 200W/4Ohm. Amplifier which can be selected as Main+Main, Main+Monitor or Main only (bridged operation, 400W/8 Ohms)
4 types of digital effects allow you to add reverb or ambiance to the mix
7 input channels compatible with mic/line level(channels 5-7 accept stereo line inputs)
3-band EQ on each input channel
2 built-in limiters prevent excessive input levels to amp modules
Dual 7-band graphic equalizers are available for both main and monitor mixes
Switchable global phantom power for all mic input connectors
Effect out for external signal processing
Tape in and out (via RCA/phono connectors) allows for connection of a tape/CD player without taking up a main input channel
8 Ohms per channel: 150 watts
4 Ohms: 200 watts
8 Ohms (bridged mono): 400 watts
Number of Power channels: 2
Limiters: 2
Inputs:
Lo-Z/Hi-Z channels: 7
Balanced Mic/ST Line channels: 3
2T input: RCA
Aux in: TRS, unbalanced
Outputs:
Main Mono: TRS, unbalanced
Monitor: TRS, unbalanced
Effect out: TRS, unbalanced
Rec. out: RCA
Channel Strips:
Aux controls: Monitor, Effect
Pad in/out: Ch 1 ~ 4
Volume Controls: Rotary
Aux send masters: Monitor, Effect
Effects Return to Monitor: Yes
Rotary Fader: Monitor, Main
Metering:
Number of channels: 2
Segments: 5
Phantom Power Supply: +48VDC
Switches: Global
Built-in Digital Effect Processor: 4 programs
Built-in Graphic EQ (2 x 7-band):
Center Frequency: 60, 120, 360, 1K, 2.5K, 7K, 16K Hz
Range: +/-12dB
Noise (20Hz to 20KHz bandwidth, IHF-A weighted, line inputs to main output) Master output, all channel level at minimum: -78dBu
Power amp output, all channel level at minimum: -63dBu
THD+N:
Power output, 20Hz to 20KHz: <0.12% @100 watts, 4 Ohms
Any output, 20Hz-20KHz@ 4dBu output: <0.06%
CMRR (1 KHz @ -60dBu, Gain at maximum): 80dB
Crosstalk (1 KHz @ -60dBu, Gain at maximum): -63dB (Channel level @ minimum, other channels at unity)
Frequency Response (Mic input to output):
20Hz ~ 20KHz, line level o/p @ +4dBu into 600 Ohms: +0/-2dB
20Hz ~ 20KHz, power amp o/p 1 watt into 8 Ohms: +0/-2dB
Maximum Levels:
Mic preamp input: +10dBu
All other inputs: +22dBu
Unbalanced outputs: +22dBu
Impedances:
Lo-Z input: 2.2KOhms
Hi-Z inputs: 5.5K Ohms
All other inputs: >10KOhms
RCA 2T outputs: 1.2KOhms
All other outputs: 560 Ohms
Equalization (3-band, +/-15dB):
Low EQ: 80Hz
Mid EQ: 2.5KHz
Hi EQ: 12 KHz
Features:
Built-in 200W + 200W/4Ohm. Amplifier which can be selected as Main+Main, Main+Monitor or Main only (bridged operation, 400W/8 Ohms)
4 types of digital effects allow you to add reverb or ambiance to the mix
7 input channels compatible with mic/line level(channels 5-7 accept stereo line inputs)
3-band EQ on each input channel
2 built-in limiters prevent excessive input levels to amp modules
Dual 7-band graphic equalizers are available for both main and monitor mixes
Switchable global phantom power for all mic input connectors
Effect out for external signal processing
Tape in and out (via RCA/phono connectors) allows for connection of a tape/CD player without taking up a main input channel
Technical Info
Power Amp Output Power in Watts (@THD<0.5%, 1KHz):8 Ohms per channel: 150 watts
4 Ohms: 200 watts
8 Ohms (bridged mono): 400 watts
Number of Power channels: 2
Limiters: 2
Inputs:
Lo-Z/Hi-Z channels: 7
Balanced Mic/ST Line channels: 3
2T input: RCA
Aux in: TRS, unbalanced
Outputs:
Main Mono: TRS, unbalanced
Monitor: TRS, unbalanced
Effect out: TRS, unbalanced
Rec. out: RCA
Channel Strips:
Aux controls: Monitor, Effect
Pad in/out: Ch 1 ~ 4
Volume Controls: Rotary
Aux send masters: Monitor, Effect
Effects Return to Monitor: Yes
Rotary Fader: Monitor, Main
Metering:
Number of channels: 2
Segments: 5
Phantom Power Supply: +48VDC
Switches: Global
Built-in Digital Effect Processor: 4 programs
Built-in Graphic EQ (2 x 7-band):
Center Frequency: 60, 120, 360, 1K, 2.5K, 7K, 16K Hz
Range: +/-12dB
Noise (20Hz to 20KHz bandwidth, IHF-A weighted, line inputs to main output) Master output, all channel level at minimum: -78dBu
Power amp output, all channel level at minimum: -63dBu
THD+N:
Power output, 20Hz to 20KHz: <0.12% @100 watts, 4 Ohms
Any output, 20Hz-20KHz@ 4dBu output: <0.06%
CMRR (1 KHz @ -60dBu, Gain at maximum): 80dB
Crosstalk (1 KHz @ -60dBu, Gain at maximum): -63dB (Channel level @ minimum, other channels at unity)
Frequency Response (Mic input to output):
20Hz ~ 20KHz, line level o/p @ +4dBu into 600 Ohms: +0/-2dB
20Hz ~ 20KHz, power amp o/p 1 watt into 8 Ohms: +0/-2dB
Maximum Levels:
Mic preamp input: +10dBu
All other inputs: +22dBu
Unbalanced outputs: +22dBu
Impedances:
Lo-Z input: 2.2KOhms
Hi-Z inputs: 5.5K Ohms
All other inputs: >10KOhms
RCA 2T outputs: 1.2KOhms
All other outputs: 560 Ohms
Equalization (3-band, +/-15dB):
Low EQ: 80Hz
Mid EQ: 2.5KHz
Hi EQ: 12 KHz
What Our Customers Say About zZounds
"The act of ordering was completely painless and straight-forward. Thanks!" - customer on November 19, 2009
Phonic PowerPod 740 7-Channel Powered Mixer Reviews
9 out of 10
"A lot of bang for your buck!"
Feature:
It's got the same features as alot of the higher end units do. I knew I wanted a combo P.A. instead of mixer and seperate power amps. I didn't need anything really huge. Before buying though, I rented several P.A. systems from the local music store. I rented a Yamaha, Peavey, and even a Mackie. I then rented a Phonic and I must say, for the money, the differences are negligable. Did I mention this unit is less that half the price of the other units? lol
Quality:
Made as well as any other unit I have tried and I've tried MANY. I would have prefered Tolex over the fur covering, but that's about it. The 2 built in cooling fans are a nice touch. I've used it to provide music for a bikini bike wash where it was running flat out for over 8 hours without a glitch.
Value:
Alot of bang for your buck.
Desirability:
THey all look alike to me.
Sound:
Really decent little P.A. for the price. Of course, we would all prefer Mackie or something. This little unit gives alot of bang for the buck. Nice smooth, clear onboard reverbs. It also has an effects loop which isn't that common on lower priced units.
Support:
N/A - I've never had a problem, therefore no reason to need their customer support.
Overall:
Very satisfied. I was leary about trying a "no-name", "generic" P.A. system. After trying it though, I was pleasently surprised.
It's got the same features as alot of the higher end units do. I knew I wanted a combo P.A. instead of mixer and seperate power amps. I didn't need anything really huge. Before buying though, I rented several P.A. systems from the local music store. I rented a Yamaha, Peavey, and even a Mackie. I then rented a Phonic and I must say, for the money, the differences are negligable. Did I mention this unit is less that half the price of the other units? lol
Quality:
Made as well as any other unit I have tried and I've tried MANY. I would have prefered Tolex over the fur covering, but that's about it. The 2 built in cooling fans are a nice touch. I've used it to provide music for a bikini bike wash where it was running flat out for over 8 hours without a glitch.
Value:
Alot of bang for your buck.
Desirability:
THey all look alike to me.
Sound:
Really decent little P.A. for the price. Of course, we would all prefer Mackie or something. This little unit gives alot of bang for the buck. Nice smooth, clear onboard reverbs. It also has an effects loop which isn't that common on lower priced units.
Support:
N/A - I've never had a problem, therefore no reason to need their customer support.
Overall:
Very satisfied. I was leary about trying a "no-name", "generic" P.A. system. After trying it though, I was pleasently surprised.
Submitted: 03/24/2005
Style of Music: Rock period. Any form of it - Ultimately, ROCK!
