The brand new JCM2000 Triple Super Lead [TSL] Series takes the critically acclaimed circuitry of the JCM2000 Dual Super Lead [DSL] range and then goes one step further.
By giving you 3 independent channels and many innovative features, the all-valve TSL range puts an unheard of degree of control, flexibility, and, most importantly, TONE at your finger tips. From crystal clean to the mightiest Marshall roar, the TSL does it all.
The JCM2000 Dual Super Lead has been hailed by players and critics alike as "The best Marshall ever made."
Features
All valve powered. [4x Svetlana EL34 power valves]
3 independent channels for Clean, Crunch, and Lead
Mid Boost Switch for tonal options on the Clean channel plus Tone Shift on the Crunch and Lead channels
Unique Marshall Deep Switch on the Clean and Crunch/Lead channels adds extra low end resonance when selected
Separate Reverb for Clean and Crunch/Lead channels
Virtual Power Reduction [VPR] gives the extra saturation of a lower powered valve amp being driven hard
Power Amp Mute switch for silent recording
Separate FX Loops with front panel Mix controls and level selection for the Clean and Crunch/Lead channels
D.I. XLR Output with acclaimed Marshall Speaker Emulation
5-way foot controller for switching channels, Reverb, and FX Loop on/off
Technical Info
Channel 1 packs a mid-boost switch, while channels 2 and 3 feature independent "tone shift" buttons. The front-panel master section includes independent reverb, effects mix, and presence knobs for the clean channel, while the lead and crunch channels share a duplicate set of these controls.
Rear panel features include 3 extension speaker jacks (allowing for 4Q, 8Q, and 16Q loads), plus an XLR line out, which features the same speaker simulator found on Marshall's JMP 1 preamp. A front-panel output mute switch allows silent recording when you're using the XLR direct out. Two parallel effects loops are provided, each with its own level switch. Loop A operates on all channels when used by itself. However, when loop B is selected (for the crunch and lead channels), loop A is active on the clean channel only.
The TSL sports a heavy-duty, welded-steel chassis and tidy construction under the hood. Multiple PC boards grip most of the circuit components (including the 4 preamp tubes), and the sockets for the 4 Svetlana EL34s are mounted on a separate subchassis.
