JBL EON G2 Sub
The Winter NAMM 2001 show in Anaheim marked the formal introduction of the EONSUB G2 from JBL Professional. A perfect companion for either the EON10 G2 or EON15 G2 powered speaker, the EONSUB G2 offers powerful low frequencies in a compact, durable enclosure and a new low price.
When you combine the EONSUB G2 with other EON G2 speakers, such as the EON10 G2, you have a full range sound system whose clarity, volume, and low end are truly amazing, considering their small size. Because the power amp and crossover are internal to all EON speakers, set up time and outboard equipment are minimized. Just plug in and play.
The EONSUB G2 powered subwoofer is consistent in design with other EON G2 models. With 250 watts of low-end power and a frequency range of 40 to 200 Hz, EONSUB G2 is also an ideal companion for any sound system needing additional low end. JBL's patented Neodymium Differential Drive? woofer generates maximum efficiency with minimum weight.
The Thermomaster cooling system allows the power amplifier and 15 in. woofer to stay cool, even under the most challenging circumstances, without the need for noisy fans or protruding external heatsinks. The SUB's cabinet was specifically designed to securely hold the EON10 G2 using receptacles built into the top of the SUB.
EONSUB G2 also underwent a facelift, with its new scratch-forgiving Black covering and embossed grill cover for added rigidity.
Technical Info
Frequency Range: (-10dB): 40 Hz - 200 Hz
Frequency Response: (?3 dB): 42 Hz - 150 kHz
Sensitivity (1w, 1m): 93 dB SPL
Rated Maximum SPL: 117dB, @ 1m (3.3 ft)
Dimensions: 686 x 430 x 444mm (27 x 17 x 17.5 in.)
Net Weight: 19.5 kg (43 lbs.)
LF Driver: Integral frame with one 15 in. (380mm) driver, dual neodymium magnet, 2 in. differential drive voice coil
Amplifier Power: 250 watts @ 2 ohms, no more than 0.1% THD
Low Pass Filter: 125 Hz, active, 2-pole
Enclosure Alignment: 6th order
Input Type: Balanced Differential
Input Sensitivity Line: +4dBu (nominal)
Speaker: 20 volts
Input Impedance Line: 16 ohms 1/2
Speaker: 143 ohms
Max Input Level Line: +28 dB
Speaker: 120 VRMS
