Emagic MT4 (Macintosh and Windows)

The new MT4 is the ideal MIDI interface for USB-equipped Notebook and Powerbook computers, or even for smaller desktop installations. Two independent inputs and 4 independent outputs, each with an activity LED, provide 32 input and 64 output MIDI channels. An external transformer is superfluous because the MT4 receives power directly via the USB port.

The introduction of the MT4 rounds out Emagic's MIDI interface series with clearly defined choices to suit all requirements. All 3 interfaces Ö Unitor8 MkII, AMT8, and MT4 Ö benefit from the same high technological standards and can be used together simultaneously.* One of the many features shared by all three devices is the software configurable Patch Mode that allows the interfaces to be used as MIDI patch bays.

The MT4's design is both robust and practical with its minimum size, minimum weight, and 2 slip-resistant rubber inserts that bind the housing and provide extra stability.

Directly supported on the Macintosh by Logic Audio and MicroLogic AV Version 4.01 and by SoundDiver 2.07 upwards, the MT4 can also be used with OMS-compatible software thanks to the supplied drivers. Under Windows 98, the support is handled via the included MME-compatible USB driver.

* Mac User: In this case the AMT8 or the Unitor MkII has to be connected to a RS422 serial port.

Technical Info

System Requirements
MacOS 9.0.4 or higher

Windows 98 SE/Me/2000/XP

The computer has to have an integrated USB 1.1 connection

An active USB 1.1 hub is needed for stand-alone use
