Manufacturer's Description for CAD Al Di Meola Acoustic Microphone Pack
Al Di Meola holds the most prestigious guitar awards of any guitarist in the world. He has been known throughout the world afor the past 2 and 1/2 decades as one of the most prominent virtuosos in the contemporary instrumental jazz field.
CAD sent Al a number of CAD instrument condensers and asked him to pick his favorites for capturing his acoustic guitar. Cad has packaged Al's top choice for stereo live and studio recording applications in this special addition Al Di Meola Acoustic Mic Pack.
e70 Modular Dual Element Condenser Microphone
Packaged in a small, rugged metal housing, the equitek e70 condenser microphone provides transparent, accurate acoustic capture. The low mass 1/2 in. gold sputtered diaphragm makes the e70 the preferred choice for high frequency sources rich in transients such as cymbal, hi-hat, strings, acoustic guitar, woodwinds and piano. The transformerless design reduces low frequency distortion at high sound pressure levels. The 3-position hi-pass filter and 3-position pad provide the versatility required in demanding live sound and studio applications. The interchangeable capsules provide both cardioid and omnidirectional pickup patterns for greater flexibility. The e70's accuracy, high SPL capability and size make it a valuable tool in the professional audio environment.
e70 Features:
Preferred choice for high frequency sources rich in transients such as cymbal, hi-hat, strings, acoustic guitar, woodwinds and piano
3-position hi-pass filter and 3-position pad
High SPL capability and size make it a valuable tool in the professional audio environment
e60 Equitek Cardiod Microphone
From the subtlest notes to a blast of brass, the e60 will capture the sound with unprecedented detail. Sophisticated electronics and a precise gold sputtered capsule provide clarity, and incredible versatility.
e60 Features:
16mm, 24k Gold sputtered externally biased condenser capsule.
10dB non-capacitive pad
4 position hi-pass filter - flat, 40Hz, 80Hz, and 120Hz
CAD's proprietary discrete linear power supply for efficient low noise and linear power regulation, allows greater dynamic range and lower equivalent self
zZounds is an authorized dealer of
CAD products.
e70
Operating Principle: End address condenser with interchangeable capsules
Frequency Response: 20Hz - 20kHz
Polar Pattern: Using Cardioid Capsule:
Sensitivity: -40dBV (10mV) @ 1 Pa
Self Noise : 23dB, A-weighted
Maximum SPL: 155dB, 20dB pad engaged
Polar Pattern: Using Omnidirectional Capsule:
Sensitivity: -36dBV (16mV) @ 1 Pa
Self Noise: 19dB, A-weighted
Maximum SPL: 154dB, 20dB pad engaged
Power Requirements: Phantom P48, 2mA
Connector: 3-pin XLR type
Polarity: Inward pressure on the diaphragm produces positive voltage on pin 2
Dimensions: 7/8 in. (22 mm) x 6 1/8 in. (156 mm)
Net Weight: 7.6 oz. (216 grams)
Included Accessories: Shockmount, mic clip and windscreen
e60
Type: Front address, externally biased condenser
Frequency response: 30Hz - 20kHz (with low end boost)
Polar Pattern: Cardioid
Impedence: Low (300 ohms nominal)
Open Circuit Voltage: -54dB (0dB = 1 volt per microbar)
Dynamic Range: 125dB
Equivalent Noise Level: 13dB Equivalent SPL, A weighted
Maximum SPL: 138dB SPL (with pad on)
Total Harmonic Distortion: Less than 0.15%
Powering: 24 - 52 Volts Phantom Power
Connector: Gold plated 3-pin XLR type
Finish: Durable Black 'leather feal' uerethane housing with black grille screen
Net Weight: 9.5oz. (270 grams)
