The Boss AC2 Acoustic Simulator is a compact effects pedal designed to accurately simulate the sounds of an acoustic guitar from a standard electric. With 4 distinct acoustic guitar modes, the AC2 gives electric guitarists the freedom to instantly "go unplugged" with the stomp of a foot pedal
Features
Delivers amazing acoustic guitar simulation using a standard electric guitar.
4 acoustic "modes" give guitarists distinct acoustic sounds.
"Standard" produces a conventional acoustic guitar sound.
"Jumbo" delivers the sound of an acoustic with a larger, more resonant body.
"Enhance" gives guitarists a brilliant, ultra-present sound to cut through in live band settings.
"Piezo" produces the bright sound of a piezo pickup.
"Top" knob adjust the effect's overall brilliance and harmonics.
"Body" adjusts the resonance of the simulated acoustic guitar body.
Level knob adjusts the overall level of the acoustic effect.
Individual outputs for effected and un-effected sound allow for the use of separate signal chains and amplifiers.
Boss 5-year warranty
Why Change Guitars When You can Simply Add the Boss AC-2 to Your Rig
A 4-mode dial selects
Standard: conventional acoustic guitar sound
Jumbo: sound of larger body acoustic guitar
Enhance: a brilliant sound that is never buried "in the mix," even while playing in a live band situation
Piezo: piezo pickup sound for a more compressed acoustic guitar sound
Individual Outputs
The AC2 has 2 individual outputs, one for the effected acoustic guitar sound, and another for the direct, unaffected electric guitar source. You can switch between outputs at the touch of a pedal and connect outputs separately to other effects units or amplifiers, for total sonic control and flexibility.
Technical Info
Nominal Input Level: -20dBm
Input Impedance: 1Mohm
Nominal Output Level: -20dBm
Output Impedance: 1kohm
Residual Noise Level: -80dBm (IHF-A weighted, typ. BODY: center, Top: center)
Controls: Level, Body, Top, Effect on/off, Mode
Indicator: CHECK (also serves as battery check indicator)
Connectors: Input, Output, E.G. out, AC adapter
Power Supply: DC9V Dry battery (6F22), AC adapter (optional PSA Series)
Current Draw: 18mA
Dimensions (W x D x H): 70 x 125 x 55mm (2-3/4 x 4-15/16 x 2-3/16 in.)
Weight (including battery): 440 g (1 lbs.)
Accessory: Dry battery (6F22)
