This microphone preamp has smooth yet punchy characteristics that drive vocal tracks to the front and warm up any digital mix. It yields up to 6 dB more gain before feedback for the live user. The pristine sound is achieved by running the tubes at a proper 250 volt plate voltage.
Features
Transformer Balanced Inputs
XLR and 1/4 in. Inputs and Outputs
+48 Volt Phantom Power
Mic/Line Level Switching
Technical Info
Frequency Response: 20Hz - 40kHz, +/- 3dB Mic/Line, 5Hz - 40kHz inst.
Input Impedance: 600 Ohm balanced low Z, 10K Ohm line, 1M Ohm Instrument
THD: 0.1% typical
S\N Ratio: 107 dB
Max Gain: 48dB Inst or line, 70dB Low Z
Indicators: 5-segment output level, +48V LEDs
Power status: LED
Input/Output jacks: XLR balanced and 1/4 in.
Dimensions 3.5 x 6 x 19 in. (89 x 162 x 482mm)
Power 120VAC (230VAC) 15VA
