The PMP1280S powered mixer delivers more power, better sound at less weight!
The PMP1280S mixer delivers 1,200 Watts of massive power and incredible performance through new-generation amplifier technology, crystal-clear sound plus an ultra-compact and lightweight design. 24-bit stereo FX processors, IMP mic preamps, Voice Canceler and more round off this impressive package of power features.
Get massive power and great sound in a lightweight package!
Features
Ultra-compact 2 x 600-Watt stereo powered mixer (1,200 Watt bridged mode)
Revolutionary amplifier technology: enormous power, incredible sonic performance and super-light weight
Ultra-compact design at nearly half the depth and weight of conventional powered mixers means no more lugging around dead weight
10-channel mixer section features 6 mono and 2 stereo channels plus separate tape returns
Two studio-grade 24-bit stereo FX processors with 100 awesome presets including reverb, chorus, flanger, delay, pitch shifter and various multi-effects
Revolutionary FBQ Feedback Detection system instantly reveals critical frequencies for easy feedback removal
Eight high-quality mic preamps with switchable +48 V phantom power for condenser microphones
Effective, extremely musical 3-band EQ, switchable Pad and Clip LEDs on all mono channels
Stereo 7-band graphic EQ allows precise frequency correction of monitor and main outputs
Voice Canceler function removes singer's voice from recordings for Karaoke applications
Selectable stereo (main L/R), double mono (main/monitor) or bridged mono amplifier operation mode
Speaker Processing function adjusts frequency response to match professional speaker systems like Behringer Eurolive series, etc.
Standby switch mutes all input channels during breaks while background music is provided via tape inputs
Adjustable stereo Aux input for connecting external signal sources
Internal switch-mode power supply, noise-free audio, superior transient response and very low power consumption
Rack mount brackets included
High-quality components and exceptionally rugged construction ensure long life
Technical Info
Loudspeaker Outputs
Type: Neutrik Speakon-compatible connecter
- Load Impedance:
+ Main L/R: 4-8 ohms
+ Monitor/Main Mono: 4-8 ohms
+ Main Mono/Main Mono:4-8 ohms
+ Bridge: 8-16 ohms
DSP:
- Converter: 24-bit Delta-Sigma, 64/128-times oversampling
- Dynamics D/A: 90 dB
- Sampling rate: 40 kHz
- Delay time: max 5 secs
- Signal run time (Line in > Line out): approx. 1.5 ms
Display:
- Type: 2 x 2-digit, 7-segment LED
Output Power:
- RMS @ 1% THD (sine wave), both channels driven:
+ 8 ohm: 215 w
+ 4 ohm: 450 w
+ Bridged Mono 8 ohm: 900 w
Peak Power, both channels driven:
+ 8 ohm: 300 w
+ 4 ohm: 600 w
+ Bridged Mono 8 ohm:1200 w
Power Supply:
- Mains Voltage: 120 V~, 60 Hz
- Fuse:T 10 A H 250 V
Power consumption: 1000 w
Mains connector: IEC standard receptacle
Physical/Weight:
- Dimensions: approx. 12 2/5 x 18 1/10 x 8 3/5 inches
- Weight: 23.33 lbs
