Operating Frequencies: UHF band
- Band C: 541.500 MHz to 566.375 MHz (996 frequencies)
- Band D: 655.500 MHz to 680.375 MHz (996 frequencies)
- Band I: 482.000 MHz to 507.000 MHz (1001 frequencies)
Not all frequencies are available in all areas. Please check with local regulations.
Minimum Frequency Step: 25 kHz
Modulation Mode: FM
Maximum Deviation: +/-35 kHz
Dynamic Range: > 110 dB (A-weighted), typical
Total Harmonic Distortion: < 1% (at 1 kHz, +/-17.5 kHz deviation)
Operating Range: 100 m (300'), typical
Open range environment with no interfering signals.
Operating Temperature Range: -5o C to +45o C (23o F to 113o F)
Battery and LCD performance may be reduced at very low temperatures.
Frequency Response: 70 Hz to 15 kHz (+1 dB, -3 dB)
Receiving System: True diversity
Image Rejection: 60 dB nominal, 55 dB minimum
RF Sensitivity: 20 dBuV at 60 dB S/N ratio
Maximum Output Level: XLR, balanced: +9 dBV; (6.3 mm), unbalanced: +7 dBV
Antenna Input: BNC-type, 50 ohms
Bias voltage 12V DC, 60 mA, each
Power Requirements: 12-18V DC, 500 mA
Dimensions: 210.0 mm (8.27") W x 164.4 mm (6.47") D x 44.0 mm (1.73") H
Not including BNC connectors or feet.
Net Weight: 1.1 kg (38.8 oz), without accessories
Accessories Included: Two flexible UHF antennas; AC adapter (country dependent); rack-mount adapters
RF Power Output: High: 30 mW, Low: 10 mW (switchable), at 50 ohms
Spurious Emissions: Following federal and national regulations
Input Connection: Four-pin Locking Connector
- Pin 1: GND
- Pin 2: INST INPUT
- Pin 3: MIC INPUT
- Pin 4: DC BIAS +5V
Batteries: Two 1.5V AA, not included
Battery Life: High: 6 hours (alkaline)
Low: 8 hours (alkaline)
Depending on battery type and use pattern.
Dimensions: 66.0 mm (2.60") W x 24.0 mm (0.94") D x 87.0 mm (3.43") H
Net Weight: 81 g (2.9 oz), without batteries
