The world-renowned Classic Series Cabinets are synonymous with bass enclosures and the sound they are expected to produce. And because Ampeg knows that players have different tastes, we make the configuration you are looking for. From the undeniable tone of the SVT-810E to the unexpected low end of the extended range SVT-410HLF, Ampeg enclosures have set the standard for decades.
All enclosures feature dual Neutrik Speak-On(r) and 1/4 in. input/output jacks. Cabinets using high frequency horns contain a variable level attenuator. To prevent overpowering and damaging the horns, a resistive bulb is wired in series with the horn for protection.
Technical Info
Dimensions: 30 x 24 x 19 in.
Weight: 110 lbs.
Component 1: Magnet Weight: 30 oz.
Component 1: Size: 4 x 10 in.
Component 1: Voice Coil: 2 in.
Component 2: Magnet Weight: 8 oz.
Component 2: Size: Horn/Driver
Component 2: Voice Coil: 1 in.
Crossover Frequency: 4 kHz
Frequency Response (-3 dB): 48 Hz - 18 kHz
Maximum SPL: 125 dB
Nominal Impedance: 4 Ohms
Program Handling: 1000 Watts
RMS Handling: 500 Watts
Sensitivity: 98 dB
Usable Low Frequency (-10dB): 28 Hz
The standard in mobile bass rigs. 500 watt cabinet at 4 ohms, 4x10" speakers w/1" horn. Speakon, 1/4" jacks. Tilt-back casters.
