AKG WMS40 Pro Flexx UHF Guitar Bug Wireless System

Manufacturer's Description for AKG WMS40 Pro Flexx UHF Guitar Bug Wireless System

Consumer Alert
Most users do not need a license to operate this wireless microphone system. Nevertheless, operating this microphone system without a license is subject to certain restrictions: the system may not cause harmful interference; it must operate at a low power level (not in excess of 50 milliwatts); and it has no protection from interference received from any other device. Purchasers should also be aware that the FCC is currently evaluating use of wireless microphone systems, and these rules are subject to change. For more information, call the FCC at 1-888-CALL-FCC (TTY: 1-888-TELL-FCC) or visit the FCC's wireless microphone website at www.fcc.gov/cgb/wirelessmicrophones

NOTE: None of the wireless systems we carry are capable of violating the FCC guidelines stated above. We are presenting this information as a matter of legally required disclosure.

Legendary AKG sound. Brilliant sound and ease of use. Unique HDAP (High Definition Audio Performance) technology ensures the best possible, realistic sound at any time.

SR40 Flexx Receiver
- Three selectable UHF frequencies for interference-free reception.

- Diversity: maximum transmission reliability even in difficult environments. The system automatically selects the antenna providing the best signal.

- Adjustable squelch

- Multichannel capability for simultaneous use of up to nine channels (maximum number of channel depends on local frequency plans).

- All-metal case

- High Definition Audio Performance technology ensures the legendary, realistic AKG sound and perfect audio transmission.

GB40 Flexx Transmitter
The GB 40 Flexx guitarbug is probably the easiest and least invasive way to integrate a guitar, bass, or portable keyboard into a wireless system in next to no time.

A "FlexJack" swiveling jack plug connects the transmitter to every type of output jack, and the GB 40 Flexx guitarbug will automatically "hug" the instrument. Therefore, and because it is incredibly small, the GB 40 Flexx guitarbug will never get in the way while you play, and keep a low profile, too.

Since the transmitter sits right on the output jack, the noiseless on/mute/off switch and status LED are always easy to check and operate. Naturally, the GB 40 Flexx guitarbug also provides an input gain control.

- Smallest switchable miniature transmitter
- 3 different battery covers included
- Swiveling FlexJack connector matching every guitar
- Extended frequency response optimized for guitars and basses
- 11 hours battery life for AAA size dry/6 hours for rechargeable zZounds is an authorized dealer of AKG products.

Specifications
SR40 Flexx
THD: typ. 0,8 % (at 1 kHz)

Signal/noise ratio: typ. 110 dB(A)

Modulation: FM

Audio outputs: bal. XLR and unbal. 1/4-inch jack, output level adjustable, at rated deviation: 500 mV rms.

Power supply: 120/230 V AC

Dimensions: 200 x 190 x 44 mm (7.8 x 7.4 x 1.7 in.)

Net weight: 665 g (1.5 lbs.)

GB40 Flexx
Carrier frequency range: 660 to 865 MHz, 3 fixed frequencies

Audio bandwidth: 40 to 20,000 Hz

THD: typ. 0.8%

Signal/noise ratio: typ. 103 dB (A)

Modulation: FM

RF output power: 5 mW (ERP)

Power supply: 1 AAA size batteries

Battery life: <11 hours (dry batteries), <6 hours (rechargeable batteries)

Dimensions: 76 x 20 x 28 mm (3 x 0.8 x 1.1 in.)

Net weight: 28 g (1 oz.) (exc. of batteries)

Patent(s): Plug (Patent no. AT 410.994, ZL 021302618, US 6,619,969)

Channel Frequencies
Channel 40A: US45
A1: 660.700 MHz
A2: 661.100 MHz
A3: 662.300 MHz

Channel 40B: US58
B1: 734.600 MHz
B2: 736.025 MHz
B3: 736.975 MHz

Channel 40C: US60
C1: 748.875 MHz
C2: 750.900 MHz
C3: 751.550 MHz
