ULX Standard UHF systems represent a breakthrough in performance and price for both working musicians and professional sound installers. Multiple system configurations provide limitless options, each with a choice of legendary Shure microphone transmitters. Over 1400 selectable, pre-programmed frequencies are available, and Automatic Frequency Selection provides a straight shot to a clear channel.
Includes
Beta87A Handheld Mic
ULXS4 Diversity Receiver
Automatic Frequency Selection
Over 1400 selectable frequencies
Predictive Diversity
RF presence LED
5'segment audio meter
3'segment transmitter battery fuel gauge
Multifunction LCD
1/2 rack design
Detachable 1/4 wave antennas
Durable plastic chassis
Locking DC connector
XLR and 1/4 in. outputs
Mic/line switchable
About ULX Series
Shure's ULX Series is wireless the way it should be - simple, agile, and bulletproof solutions that are affordable for working musicians and professional sound installers. Wireless traffic jamming your transmissions? The frequency agile ULX features Automatic Frequency Selection finds open frequencies for you. Whether ULX Standard or Professional Series Systems, the clear channels and strong transmission free you to concentrate on what matters most - your sound.
Technical Info
Channel Frequencies
Channel J1: 554 to 590 MHz
Channel M1: 662 to 698 MHz
System Includes: ULXS4 Standard Diversity Receiver, ULX2/BETA87A Handheld Transmitter with BETA 87A Microphone.
RF Carrier Frequency Range: 554.000 to 865.000 MHz (Available frequencies depend on the applicable regulations in the country where the system is used).
Refer to the frequency supplement supplied with the system.
Effective Range: 100 m (300 ft.) under optimal conditions
NOTE: Actual working range depends on RF signal absorption, reflection, and interference
Audio Frequency Response: 25 to 15,000 Hz, +/-2 dB
NOTE: Overall system frequency response depends on the microphone element.
*Output Level: Microphone Level = Line Level - 20 dB
Transmitter Audio Polarity: Positive pressure on microphone diaphragm (or positive volt-age applied to tip of WA302 phone plug) produces positive voltage on pin 2 (with respect to pin 3 of low impedance output) and the tip of the high impedance 1 / 4 -inch output
Transmitter Gain Adjustment Range ULX2: 25 dB
Receiver Audio Output Level (+/-38 kHz deviation, 1 kHz tone):
XLR connector (into 600 ohm load): +3.9 dBV (line), -17dBV mic
